SQH Qick Open Multi Bag Filter Housings

SQH Qick Open Multi Bag Filter Housings SQH multi bag filter housing is designed for quick open than traditional armed lifting closure. The hand wheel can be operated by single hand and the closure can be opened to random angle as it is.

Range: Filter Housings
Type: SS Bag Filter Housings
Supplier: Shanghai Liquapure Filtration Co., Ltd, Shanghai, China
Customisation: Micron rating, length and end cap specified to your housing
Photographs on file: 1

Call +86 137 6415 7715 Contact Details

Details

Full Description

SQH Qick Open Multi Bag Filter Housings

SQH multi bag filter housing is designed for quick open than traditional armed lifting closure. The hand wheel can be operated by single hand and the closure can be opened to random angle as it is self-balance. It is suitable for applications where bags need to be changed frequently

filtration housing

Features & Benefits

Quick open for fast bag change-out
Ergonomic Design for single hand operating
• High flow rate, up to accept 23 pieces #2 bags

Specifications & Operating Parameters

Max. Pressure: 150 psi

Inlet/Outlet: Flanged

Finish: Polished or sand blast

Ordering information

e.g.: SQH-10-S4-6-A-B

Code

Bags

Material

Flange

O-rings

SBS

…

S4=SS304

S6=SS316L

3”

6”

8”

10”

A=ANSI

D=DIN

J-JIS

B=Buna

E=EPDM

S=Silicone

V=Viton

FAQ

Questions About This Product

Will this fit my existing housing

Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.

Which micron ratings and lengths are available

Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.

What is the production capacity

Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.

Which industries is this used in

Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.

How do I get a quotation

Call +86 137 6415 7715 with the specification and the quantity you need.
