SBT Top Inlet Bag Filter Housings

SBT Top Inlet Bag Filter Housings SBT series bag filter housing is the most optimal bag type housing as the fluids get in from the side inlet then through the top to the bag filter, which decrease the turbulence and pressure loss and.

Range: Filter Housings
Type: SS Bag Filter Housings
Supplier: Shanghai Liquapure Filtration Co., Ltd, Shanghai, China
Customisation: Micron rating, length and end cap specified to your housing
Photographs on file: 1

Call +86 137 6415 7715 Contact Details

Details

Full Description

SBT Top Inlet Bag Filter Housings

SBT series bag filter housing is the most optimal bag type housing as the fluids get in from the side inlet then through the top to the bag filter, which decrease the turbulence and pressure loss and protect the bag. The adjustable heavy-duty legs are equipped for easy mount.

bag filtration housing

Features & Benefits

Top inlet for critical needs.
Adjustable heavy duty legs
Low pressure drop, high flow rate

Specifications & Operating Parameters

Max. Pressure: 150 psi
Inlet/Outlet: Flange
Finish: Polished or sand blast

Ordering information:

e.g.: SBT-2-S4-2-A-E

Code

Bag Size

Material

Flange

O-rings

SBC

S4=SS304

S6=SS316L

2”

A=ANSI

D=DIN

J-JIS

B=Buna

E=EPDM

S=Silicone

V=Viton

FAQ

Questions About This Product

Will this fit my existing housing

Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.

Which micron ratings and lengths are available

Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.

What is the production capacity

Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.

Which industries is this used in

Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.

How do I get a quotation

Call +86 137 6415 7715 with the specification and the quantity you need.
