Sanitary Filter Housings

Sanitary Filter Housings MSH series multi-round sanitary liquid filter housings are constructed of SS316L for high purity critical filtration needs such as pharmacy, beverage and fine chemicals. The housings are available in single round.

Range: Filter Housings
Type: Sanitary Filter housings
Supplier: Shanghai Liquapure Filtration Co., Ltd, Shanghai, China
Customisation: Micron rating, length and end cap specified to your housing
Photographs on file: 1

Call +86 137 6415 7715 Contact Details

Details

Full Description

Sanitary Filter Housings

MSH series multi-round sanitary liquid filter housings are constructed of SS316L for high purity critical filtration needs such as pharmacy, beverage and fine chemicals. The housings are available in single round or multi-round for flow rate requirements, and are designed with 222 or 226 adapters for safety seal.

filter cartridge filter housing

Features

Durable 316L stainless steel for corrosion resistance
Sanitary vent and drain valves permit easy venting, draining, sampling
Tri-clamp or swing bolt closure for easy change-out
Electropolished inside and out enhances cleanability

Applications

Wine/Beer/Bottled Water
Fine chemicals
Pharmacy
Electronics

Specifications

Finish: Electropolished
Inlet/outlet: Flange or Tri-clamp

Operating Parameters

Max. Pressure: 150 psi (10 bar)
Max. Temperature: 150 ℃

Materials of Construction

Housing: SS316, SS304
O-ring: Buna, Silicone, EPDM, Viton

Ordering Information e.g.:

MSH-5-30-6-S6-2-T-E

Code

Filters

Length

Adapter

Material

Inlet/Outlet

O-rings

MSH

10”

20”

30”

40”

2=222

6=226

S4=SS304

S6=SS316L

1”

1.5”

2”

3”

T=Tri-clamp

F=Flange

B=Buna

E=EPDM

S=Silicone

V=Viton

FAQ

Questions About This Product

Will this fit my existing housing

Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.

Which micron ratings and lengths are available

Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.

What is the production capacity

Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.

Which industries is this used in

Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.

How do I get a quotation

Call +86 137 6415 7715 with the specification and the quantity you need.
