SSH Series Single Round sanitary filter housings
are available in T-type and inline style. The housings are designed with sanitary, single cartridge for clarification, sterilization, or high purity filtration of liquids and gases. It offers continuous small batch processing applications.
SS housings
Features
- Inline flow configuration reduces pressure loss
- Thermal jacket available for steam or coolant circulation
- Tri-clamp for easy change-out
- Sanitary grade enhance cleanability
Applications
- Food and beverage
- Fine chemicals
- Pharmacy
- Laboratory
Specifications
- Finish: Electropolished
- Inlet/outlet: Tri-clamp
Operating Parameters
- Max. Pressure: 100 psi
- Max. Temperature: 150 ℃
Materials of Construction
- Housing: SS316, SS304
- O-ring: Buna, Silicone, EPDM, Viton
Ordering information e.g.:
SSH
| Code | Type | Length | Material | Adapter | O-rings |
| SSH | T=T-type
I=Inline |
5”
10” 20” |
S4=SS304
S6=SS316L |
2=222
6=226
|
E=EPDM
S=Silicone V=Viton |
FAQ
Questions About This Product
Will this fit my existing housing
Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.
Which micron ratings and lengths are available
Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.
What is the production capacity
Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.
Which industries is this used in
Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.
