Multi-Cartridge Filter Housings

SCC Clamp Cartridge Filter Housings SCC series stainless steel cartridge filter housings are designed with V band clamp closure for quick change-out of commercial and light industrial water applications. Standard max pressure is 100 psi,.

Range: Filter Housings
Type: SS cartridge Filter Housings
Supplier: Shanghai Liquapure Filtration Co., Ltd, Shanghai, China
Customisation: Micron rating, length and end cap specified to your housing
Photographs on file: 1

Call +86 137 6415 7715 Contact Details

Details

Full Description

SCC Clamp Cartridge Filter Housings

SCC series stainless steel cartridge filter housings are designed with V band clamp closure for quick change-out of commercial and light industrial water applications. Standard max pressure is 100 psi, and 150 psi is available as request.

Features & Benefits

V-band clamp closure for quick and easy cartridge change out and secure sealing
Hold 3,5,7 cartridges from 10″ to 40″ length for choice of flow rates
Accept both SOE 222 and DOE cartridges.
Adjustable top plate to accept variety length

Specifications & Operating Parameters

Max. Pressure: Standard 100 psi
Custom 150 psi
Inlet/Outlet: NPT, BSP
Finish: Polished or sand blast

Ordering information

e.g.: SCC-7-40-S4-2-N-B

Code

Filters

Length

Material

Thread

O-rings

SCC

S4=SS304

S6=SS316L

1”

1.5”

2”

2.5”

N=NPT

B=BSP

B=Buna

E=EPDM

S=Silicone

V=Viton

Pictures:

filter housing

Liquapure filtration Co.,ltd

www.liquapure.com [email protected] MB:+86 13764157715

FAQ

Questions About This Product

Will this fit my existing housing

Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.

Which micron ratings and lengths are available

Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.

What is the production capacity

Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.

Which industries is this used in

Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.
