Lenticular Filter Housings

Lenticular Filter Housings LRH series stainless steel lenticular filter housings are constructed of SS316L for the lenticular filters in both 12” and 16” for food and beverage industries. The housings are designed for easy disassembly,.

Range: Filter Housings
Type: SS cartridge Filter Housings
Supplier: Shanghai Liquapure Filtration Co., Ltd, Shanghai, China
Customisation: Micron rating, length and end cap specified to your housing
Photographs on file: 1

Call +86 137 6415 7715 Contact Details

Details

Full Description

Lenticular Filter Housings

LRH series stainless steel lenticular filter housings are constructed of SS316L for the lenticular filters in both 12” and 16” for food and beverage industries. The housings are designed for easy disassembly, cleaning, draining and sampling. Electropolished finish achieve sanitary grade.

filters

Features

Total enclosed depth filtration
User friendly vertical design
Tri-clamp and swing bolt closure for easy change-out
Electropolished inside and out enhances cleanability

Applications

Wine/Beer/Juice
Enzyme solutions
Liquor gelatin,
Olive oil

Specifications

Filter Diameter: 12”, 16”
Inlet/outlet: Tri-clamp
Finish: Electropolished

Operating Parameters

Max. Pressure: 150 psi (10 bar)
Max. Temperature: 150 ℃

Materials of Construction

Wet Parts: SS316L
Legs and clamp: SS304
O-ring: EPDM

Ordering Information e.g.:

LRH-16-2-S6-3T-E

Code

Diameter

Modules

Material

Inlet/Outlet

O-rings

LRH

12”

16”

S4=SS304

S6=SS316L

1”

1.5”

2”

3”

T=Tri-clamp

B=Buna

E=EPDM

S=Silicone

V=Viton

FAQ

Questions About This Product

Will this fit my existing housing

Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.

Which micron ratings and lengths are available

Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.

What is the production capacity

Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.

Which industries is this used in

Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.

How do I get a quotation

Call +86 137 6415 7715 with the specification and the quantity you need.
