Liquapure multi-cartridge filter housings

Liquapure multi-cartridge filter housings are designed for applications where stainless steel is not suitable such as sea water, chemicals and other corrosive liquid. PVC filters Features PVC, PP for chemical resistance Light weight,.

Range: Filter Housings
Type: Plastic Filter Housings
Supplier: Shanghai Liquapure Filtration Co., Ltd, Shanghai, China
Customisation: Micron rating, length and end cap specified to your housing
Photographs on file: 1

Call +86 137 6415 7715 Contact Details

Details

Full Description

Liquapure multi-cartridge filter housings are designed for applications where stainless steel is not suitable such as sea water, chemicals and other corrosive liquid.

PVC filters

Features

PVC, PP for chemical resistance
Light weight, High strength
Option with clamp and swing closure
Max. 9 round 40” for high flow rate

Applications

Sea water, desalination
Acids, alkali solvents
Food and beverage
Coating and paint

Operating Parameters

Max. Temperature: 45 ℃
Max. Pressure: Swing bolt @ 6 bar
Clamp @ 4 bar

Ordering Information e.g.: CCH-5-20-S-D5

Code

Filters

Length

Closure

Inlet/outlet

CCH

PCH

10”

20”

30”

40”

C=Clamp

S=Swing

D4=DN40

D5=DN50

D8=DN80

FAQ

Questions About This Product

Will this fit my existing housing

Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.

Which micron ratings and lengths are available

Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.

What is the production capacity

Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.

Which industries is this used in

Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.

How do I get a quotation

Call +86 137 6415 7715 with the specification and the quantity you need.
