HFOF Series Cartridge Filters

HFOF Series Cartridge Filters HFOF series cartridge filters are designed for oil and gas industries. The high-performance cartridge is manufactured for filtration of oilfield fluids as completion fluids, work over fluids, injection water..

Range: Filter Cartridges
Type: Depth pleated Filter Cartridges
Supplier: Shanghai Liquapure Filtration Co., Ltd, Shanghai, China
Customisation: Micron rating, length and end cap specified to your housing
Photographs on file: 1

Call +86 137 6415 7715 Contact Details

Details

Full Description

HFOF Series Cartridge Filters

HFOF series cartridge filters are designed for oil and gas industries. The high-performance cartridge is manufactured for filtration of oilfield fluids as completion fluids, work over fluids, injection water. The large surface filter cartridge has a multi-layer structure for absolute filtration, high dirt holding capacity and extend the filter service life.

oil filter

Features

Designed for oilfield fluids
Single piece rigid cage and sleeve option
High flow rate, low pressure drop
High dirt holding capacity

Applications

Well completion fluids
Work over fluids
Injection water
Polishing brines
Process water

Dimensions

Outer Diameter: 64mm
Length: 30”, 40”

Materials of Construction

Media: Polypropylene, Polyester, Fiberglass
Core: Polypropylene
Cage: Polypropylene, sleeve
Adapter: 222/Flat (Polypropylene, ABS)

Operating Parameters

Max. Temperature: 80℃
Max. Differential Pressure: 2.4 bar

Ordering Information e.g.: HFOF-5-40-C-P-B

Code

Micron

Length

Outer

Media

O-ring

HFOF

30”

40”

Cage

Sleeve

P=PP

G=Fiberglass

B=Buna

S=Silicone

E=EPDM

V=viton

FAQ

Questions About This Product

Will this fit my existing housing

Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.

Which micron ratings and lengths are available

Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.

What is the production capacity

Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.

Which industries is this used in

Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.

How do I get a quotation

Call +86 137 6415 7715 with the specification and the quantity you need.
