8” SS Membrane Pressure Vessels
8” SS Membrane Pressure Vessels 8 inch stainless steel membrane pressure vessels are designed for 8” RO, Nano, and UF membranes for filtration, separation and concentration purpose. SVE, SVS are for general industrial water treatment, HSV.
- Range
- Membrane Vessels
- Supplier
- Shanghai Liquapure Filtration Co., Ltd, Shanghai, China
- Customisation
- Micron rating, length and end cap specified to your housing
- Photographs on file
- 1
Details
Full Description
8” SS Membrane Pressure Vessels
8 inch stainless steel membrane pressure vessels are designed for 8” RO, Nano, and UF membranes for filtration, separation and concentration purpose. SVE, SVS are for general industrial water treatment, HSV is 1000 psi side Victaulic port housings for high pressure purpose, HST is 1000 psi with tri-clamp side port for sanitary process applications.
Features & Benefits
- No seals involved in side port connections
- Sanitary available for critical process water
- Sanitary grade accept 40” and 38” RO membranes.
- Max. 6 elements acceptable
Ordering Information:
| Code | Diameter | Length | Inlet | Outlet | Port | Max. Pressure |
| SVE8040 | 8“ | 40″ | 1 1/2″ | 1″ | end | 300 psi |
| SVE8080 | 8“ | 80″ | 1 1/2″ | 1″ | end | |
| SVE80120 | 8“ | 120″ | 1 1/2″ | 1″ | end | |
| SVE80160 | 8“ | 160″ | 1 1/2″ | 1″ | end | |
| SVE80200 | 8“ | 200″ | 1 1/2″ | 1″ | end | |
| SVE80240 | 8“ | 240″ | 1 1/2″ | 1″ | end | |
| SVS8040 | 8“ | 40″ | 1 1/2″ | 1″ | side | |
| SVS8080 | 8“ | 80″ | 1 1/2″ | 1″ | side | |
| SVS80120 | 8“ | 120″ | 1 1/2″ | 1″ | side | |
| SVS80160 | 8“ | 160″ | 1 1/2″ | 1″ | side | |
| SVS80200 | 8“ | 200″ | 1 1/2″ | 1″ | side | |
| SVS80240 | 8“ | 240″ | 1 1/2″ | 1″ | side | |
| HSV8040 | 8“ | 40″ | 3″ | 1″ | side victaulic | 1000 psi |
| HSV8080 | 8“ | 80″ | 3″ | 1″ | side victaulic | |
| HSV80120 | 8“ | 120″ | 3″ | 1″ | side victaulic | |
| HSV80160 | 8“ | 160″ | 3″ | 1″ | side victaulic | |
| HSV80200 | 8“ | 200″ | 3″ | 1″ | side victaulic | |
| HSV80240 | 8“ | 240″ | 3″ | 1″ | side victaulic | |
| HST8040 | 8“ | 40″ | 3″ | 1 1/2″ | side triclamp | |
| HST8080 | 8“ | 80″ | 3″ | 1 1/2″ | side triclamp | |
| HST80120 | 8“ | 120″ | 3″ | 1 1/2″ | side triclamp | |
| HST80160 | 8“ | 160″ | 3″ | 1 1/2″ | side triclamp | |
| HST80200 | 8“ | 200″ | 3″ | 1 1/2″ | side triclamp | |
| HST80240 | 8“ | 240″ | 3″ | 1 1/2″ | side triclamp |
SS vessels
FAQ
Questions About This Product
Will this fit my existing housing
Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.
Which micron ratings and lengths are available
Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.
What is the production capacity
Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.
Which industries is this used in
Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.
How do I get a quotation
Call +86 137 6415 7715 with the specification and the quantity you need.
