FRP pressure vessels | Liquapure Filtration

Liquapure FRP pressure vessels are available for both membrane elements and high flow cartridge filters. For membrane filtration, the vessels are provided with 2.5”, 4” and 8” diameter and range in pressure from 300 psi to 1200 psi for RO,.

Range: Membrane Vessels
Type: FRP pressure vessels
Supplier: Shanghai Liquapure Filtration Co., Ltd, Shanghai, China
Customisation: Micron rating, length and end cap specified to your housing
Photographs on file: 1

Call +86 137 6415 7715 Contact Details

Details

Full Description

FRP vessels water treatment

Code	Diameter	Pressure	Elements	Port	Temperature
FRP40E30	4″	300 psi	1-5	End	＜49℃
FRP40S30	4″	300 psi	1-5	End	＜49℃
FRP40E100	4″	1000 psi	1-5	End	＜49℃
FRP40S100	4″	1000 psi	1-5	Side	＜49℃
FRP80E30	8″	300 psi	1-7	End	＜49℃
FRP80S30	8″	300 psi	1-7	Side	＜49℃
FRP80S100	8″	1000 psi	1-7	Side	＜49℃

* 450, 600, 800, 1200 psi available.

FAQ

Questions About This Product

Will this fit my existing housing

Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.

Which micron ratings and lengths are available

Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.

What is the production capacity

Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.

Which industries is this used in

Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.

How do I get a quotation

Call +86 137 6415 7715 with the specification and the quantity you need.
