4” SS Membrane Pressure Vessels
4” SS Membrane Pressure Vessels Stainless steel membrane housings are available with various pressure ratings and sanitary grade for commercial, industrial and process separation RO, Nano and UF membranes. SVE, SVS are for commercial and.
- Range
- Membrane Vessels
- Supplier
- Shanghai Liquapure Filtration Co., Ltd, Shanghai, China
- Customisation
- Micron rating, length and end cap specified to your housing
- Photographs on file
- 1
Details
Full Description
4” SS Membrane Pressure Vessels
Stainless steel membrane housings are available with various pressure ratings and sanitary grade for commercial, industrial and process separation RO, Nano and UF membranes.
SVE, SVS are for commercial and light industrial water treatment. SSV is for sanitary grade, HSE, HSS are 1000 psi Membrane housings.
Features & Benefits
- Resistant to UV and sunlight
- Easier to handle than FRP or PVC
- Double O rings for sealing integrity
- SS304 or SS316L option
- Seamless or seamed option for SVE, SVS series
Ordering Information:
| Model | Diameter | Length | Inlet | Outlet | Port | Max. Pressure |
| SVE4040 | 4″ | 40″ | 3/4″ | 1/2″ | end | 300psi |
| SVE4080 | 4″ | 80″ | 3/4″ | 1/2″ | end | |
| SVE40120 | 4″ | 120″ | 3/4″ | 1/2″ | end | |
| SVE40160 | 4″ | 160″ | 3/4″ | 1/2″ | end | |
| SVS4040 | 4″ | 40″ | 3/4″ | 1/2″ | side | |
| SVS4080 | 4″ | 80″ | 3/4″ | 1/2″ | side | |
| SVS40120 | 4″ | 120″ | 3/4″ | 1/2″ | side | |
| SVS40160 | 4″ | 160″ | 3/4″ | 1/2″ | side | |
| SSV4040 | 4″ | 40″ | 1″ | 3/4″ | side | 400psi |
| SSV4080 | 4″ | 80″ | 1″ | 3/4″ | side | |
| SSV40120 | 4″ | 120″ | 1 1/4″ | 3/4″ | side | |
| SSV40160 | 4″ | 160″ | 1 1/2″ | 3/4″ | side | |
| HSE4040 | 4″ | 40″ | 3/4″ | 1/2″ | end | 1000psi |
| HSE4080 | 4″ | 80″ | 3/4″ | 1/3″ | end | |
| HSE40120 | 4″ | 120″ | 3/4″ | 1/4″ | end | |
| HSE40160 | 4″ | 160″ | 3/4″ | 1/5″ | end | |
| HSS4040 | 4″ | 40″ | 3/4″ | 1/6″ | side | |
| HSS4080 | 4″ | 80″ | 3/4″ | 1/7″ | side | |
| HSS40120 | 4″ | 120″ | 3/4″ | 1/8″ | side | |
| HSS40160 | 4″ | 160″ | 3/4″ | 1/9″ | side |
SS filters
FAQ
Questions About This Product
Will this fit my existing housing
Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.
Which micron ratings and lengths are available
Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.
What is the production capacity
Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.
Which industries is this used in
Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.
How do I get a quotation
Call +86 137 6415 7715 with the specification and the quantity you need.
