Bronze/Stainless Steel/Copper Electric/Hydraulic/Pneumatic Marine flanged ball valves Ball Valve for Ship

Application

Bronze/Stainless Steel/Copper Electric/Hydraulic/Pneumatic Marine ball valves for Ship Marine Ball valves Bronze/Stainless Steel flanged Ball Valve for ship What’s more, The Marine ball valves is carefully polishing and testing before leaving factory to ensure the performance. In addition, Copper&Bronze/Stainless Steel material has longer service life for your pipes&vessel. Classification of flanged ball valves by structure 1 Floating ball valve The ball of a ball valve is floating, and under the action of medium pressure, the ball can generate a certain displacement and tightly press on the sealing surface of the outlet end, ensuring the sealing of the outlet end. The floating ball valve has a simple structure and good sealing performance, While the ball bears all the load of the working medium and is transmitting to the outlet sealing ring. Therefore, it is necessary to consider whether the sealing ring material can withstand the working load of the ball medium. This structure is widely using for medium and low pressure ball valves 2. Fixed ball valve The ball of a flanged ball valve is fixed and does not move under pressure. Fixing ball valves are equipped with floating valve se

Tell us vessel type, chain or opening size, voltage or hydraulic preference, and the class society. Star Marine will confirm the model, shop-test the unit, and pack it for sea or air freight.

Warranty and documents

One year warranty after the cargo arrives at the vessel, with installation guidance and spare-parts support. Where a product card lists a longer deck-machinery warranty, that period applies to that line. Product certificates under ABS, BV, CCS, DNV, GL, LR or RINA can be arranged; BV and CCS are the most commonly requested.
