Porcelain Insulators · Station Post
Porcelain Station Post Insulators C4-125
Key Data
Huaci engineers provide OEM service to meet the varying needs from customers.
Specifications
All values as published in the Huaci catalogue.
| Diameter (D) | 130mm |
|---|---|
| Spacing (H) | 305mm) |
| Creepage Distance | 500mm |
| Net Weight Each | 6.6kg |
| Cantilever Strength | 4kN |
|---|---|
| Torsion Strength | 600N-m |
| Power Frequency Dry Withstand Voltage | 60kV |
|---|---|
| Power Frequency Wet Withstand Voltage | 50kV |
| Lightning Impulse Withstand Voltage | 125kV |
Standards
Huaci strictly comply with GB, ANSI, BS, DIN, AS and IEC standard designs, applicable to power transmission lines and substations.
Quality Systems
ISO 9001:2015 Quality Management, ISO 14001:2015 Environment Management and ISO 45001:2018 Occupational Health And Safety Management System certificates.
Export Record
Huaci products are exported to more than 40 countries and have performed well in a variety of global environments.
Related Products
All Station Post →
Porcelain Ball and Socket Type Suspension Insulators ANSI 52-3
Porcelain Clevis Type Suspension Insulators ANSI 52-1
Porcelain Clevis Type Suspension Insulators ANSI 52-4
Porcelain Pin Insulators ANSI 55-4
Porcelain Pin Post Insulators 56/57-2
Porcelain Shackle Insulators ED-2B
Porcelain Spool Insulators ANSI 53-2
Porcelain Strain Insulators ANSI 54-2
FAQ
About Porcelain Station Post Insulators C4-125
What is the cantilever strength of Porcelain Station Post Insulators C4-125?
The published cantilever strength of Porcelain Station Post Insulators C4-125 is 4kN.
What does Porcelain Station Post Insulators C4-125 weigh?
The published net weight is 6.6kg each.
What is the creepage distance of Porcelain Station Post Insulators C4-125?
The published creepage distance is 500mm.
Which design standards does Huaci comply with?
Huaci strictly comply with GB, ANSI, BS, DIN, AS and IEC standard designs, applicable to power transmission lines and substations.
What system voltages are covered?
Huaci specialises in insulator manufacture up to 500 kV AC and 400 kV DC system voltages.
Is OEM or customised production available?
Yes. Huaci engineers are able to provide OEM service to meet the varying needs from customers and assist the customers to develop their market better.
Which quality certificates does the factory hold?
Quality Management System Certificate ISO 9001:2015, Environment Management System Certificate ISO 14001:2015 and the Occupational Health And Safety Management System Certificate ISO 45001:2018.
Request A Quotation For Porcelain Station Post Insulators C4-125
Send the quantity and destination port and Huaci will reply with pricing, packing details and lead time.
