Polyphase Meter Box

Polyphase Meter Box for EDEESUR, EDENORTE, EDESUR

  • Suitable for receiving a single-phase or two-phase meter with energy boxes the thermo-magnetic switch or a three-phase meter without switch. It allows to install removable gauges type “socket” or meters “bottom”, according to the case is provided with respective accessories. Optionally you can install a device for driving a unipolar or bipolar
Request A Quote Email Us Request A Sample
GroupABC Accessories
CategoryDistribution Boxes and Enclosures
StandardsIEC and GB
CustomisationOEM and non standard accepted
Polyphase Meter Box
OverviewGalleryOrderingFAQRelated

Overview

Polyphase Meter Box Description

PMB005(No-breaker)

Size: 345×207×200 Height: 345mm Base height: 120mm Base deep: 109mm Width: 207mm System Voltage: 120V/240V, Max: 600V Current: 100A, Max: 125A Max earth conductor size: 25mm2 Cable Gland: 2×M32, 1×M21 Contacting: copper tinned with Stainless steel “S” Accessories Connector: copper tinned with Allen head screw Comply with UNE 50298

PMB005(120V)

Size: 345×207×200 Height: 345mm Base height: 120mm Base deep: 109mm Width: 207mm System Voltage: 120V/240V, Max: 600V Current: 100A, Max: 125A Max earth conductor size: 25mm2 Breaker: 600V, 1P, C, 40A, 10kA Cable Gland: 2×M32, 1×M21 Contacting: copper tinned with Stainless steel “S” Accessories Connector: copper tinned with Allen head screw Comply with UNE 50298

PMB005(240V)

Size: 345×207×200 Height: 345mm Base height: 120mm Base deep: 109mm Width: 207mm System Voltage: 120V/240V, Max: 600V Current: 100A, Max: 125A Max earth conductor size: 25mm2 Breaker: 600V, 2P, C, 63A, 10kA Cable Gland: 2×M32, 1×M21 Contacting: copper tinned with Stainless steel “S” Accessories Connector: copper tinned with Allen head screw Comply with UNE 50298

Ordering and Support

From Enquiry To Delivered Order

1

Send The Requirement

Item code, conductor or cable size and quantity, or a drawing and a photograph for a non standard part.

2

Quotation

Price, packing, carton quantity and lead time are confirmed against the catalogue reference.

3

Sample or Tooling

Samples are sent for approval. Parts that need a new mould go through the in house mould division.

4

Production and Shipment

Production to IEC and GB standards, then packing and shipment on the agreed terms.

Answers

Frequently Asked Questions

Is Polyphase Meter Box available as a sample before a production order?
Yes. Ask for a sample by WhatsApp on 0086 138 6832 9796 or by email and the item, the packing and the lead time for a full order will be confirmed together.
Which standards do CROP products follow?
All CROP products are made to comply with IEC and GB standards. Where a project calls for a national or utility specification, send the standard reference with your enquiry and the matching item will be quoted.
Can items be produced to our own drawing?
Yes. Non-standard and OEM orders are part of the normal range. Send the drawing, a picture, the weight or the written specification to [email protected] or by WhatsApp and a quotation will be prepared against your requirement. CROP also runs its own mould division for plastic, SMC and stamped parts.
How do I obtain the PDF catalogue?
The catalogue is issued on request. Ask for the section you need by email or WhatsApp on 0086 138 6832 9796 and the PDF will be sent back to you. The catalogue page lists every section that is available.
