Line Tap Connector

Hot Line Tap Clamps LLC Series

For Aluminum, ACSR, and armor rod covered aluminum or ACSR conductor. For installation on energized conductor.

  • For Aluminum, ACSR, and armor rod covered aluminum or ACSR conductor. For installation on energized conductor.
Request A Quote Email Us Request A Sample
GroupPower Connectors
CategoryLine Tap Connector
StandardsIEC and GB
CustomisationOEM and non standard accepted
Hot Line Tap Clamps LLC Series
OverviewSpecificationsGalleryOrderingFAQRelated

Overview

Hot Line Tap Clamps LLC Series Description

HOT LINE TAP CLAMPS

Description For Aluminum, ACSR, and armor rod covered aluminum or ACSR conductor. For installation on energized conductor. Material Body and Keeper – Aluminum Alloy Eye bolt – Bronze alloy – Tin Plated Eyestem – Bronze alloy, Forged or stainless steel Spring (on eyestem) Stainless Steel

Specifications

Codes Ranges and Dimensions

Figures below are reproduced from the CROP catalogue for this item.

Models:LLC1520E1030-ACLLC1530
Main Line(mm²)16-7010-12016-185
Service Line (mm ² )16-5010-7016-95
Main Line(AWG)6 sol-2/0 str al8 sol-4/0 str al6 sol- 400MCM al
Service Line (AWG)6 sol-1/0 str al/cu8 sol-2/0 str al/cu6 sol-2/0 al/cu
Bolt No.111

Ordering and Support

From Enquiry To Delivered Order

1

Send The Requirement

Item code, conductor or cable size and quantity, or a drawing and a photograph for a non standard part.

2

Quotation

Price, packing, carton quantity and lead time are confirmed against the catalogue reference.

3

Sample or Tooling

Samples are sent for approval. Parts that need a new mould go through the in house mould division.

4

Production and Shipment

Production to IEC and GB standards, then packing and shipment on the agreed terms.

Answers

Frequently Asked Questions

How do I choose the right size?
Match your conductor or cable size against the range column in the specification table on this page, then quote the code on that row. If the size falls between two rows, send both figures with your enquiry and the correct item will be confirmed.
Is Hot Line Tap Clamps LLC Series available as a sample before a production order?
Yes. Ask for a sample by WhatsApp on 0086 138 6832 9796 or by email and the item, the packing and the lead time for a full order will be confirmed together.
Which standards do CROP products follow?
All CROP products are made to comply with IEC and GB standards. Where a project calls for a national or utility specification, send the standard reference with your enquiry and the matching item will be quoted.
Can items be produced to our own drawing?
Yes. Non-standard and OEM orders are part of the normal range. Send the drawing, a picture, the weight or the written specification to [email protected] or by WhatsApp and a quotation will be prepared against your requirement. CROP also runs its own mould division for plastic, SMC and stamped parts.
How do I obtain the PDF catalogue?
The catalogue is issued on request. Ask for the section you need by email or WhatsApp on 0086 138 6832 9796 and the PDF will be sent back to you. The catalogue page lists every section that is available.

Next Step

Get A Price For Hot Line Tap Clamps LLC Series

Send the code, the size and the quantity. Drawings for non standard versions are welcome.
