Magnetic Track Light

ARC Magnetic Track Flood Light

Arc-shaped magnetic track LED flood light is specially designed for circle linear track lighting. These led track lights comes with frosted Acrylics diffuser with wide lighting beam 120°。

Request A Quote Talk To An Engineer Email Us

Custom builds to your drawing
Small and sample orders accepted
OEM and ODM welcome

Overview

Product Overview

Arc-shaped magnetic track LED flood light is specially designed for circle linear track lighting. These led track lights comes with frosted Acrylics diffuser with wide lighting beam 120°。Now we have 8W and 16W for option. Seven Colors Lighting equips them with Osram high CRI>90Ra LED light bulbs to make your space more cozy.

Highlights

Key Features

CRI>90Ra
SDCM<5
Life Span>50000HRS
Efficiency>87%

Technical Data

Specifications

Item No.	SC-ARF-02
Power	16W
Dimension	L360XW22XH25mm
Working Voltage	AC85-265V
Output Voltage	DC48V
LED Chip Brand	Osram led chip
Driver	Meanwell led driver DC48V
Installation	attached to the track
Lumen Flux	1620-1800LM
Material	Aluminum
Finish	Black/white
Beam Angle	120°
IK Rate	IK07
IP Rating	IP24 Indoor using
Dimmable	support 0-10V /DALI or Zigbee
Working Temperature	-25℃～+50℃
Storage Temperature	-30℃～+55℃
Standard	US/AU/EU Standard
Warranty	2/3 years

Detail Views

Product Gallery

How We Work

Customisation and Ordering

Made To Your Design

Seven Colors Lighting makes products to your design, drawing or idea. Send a sketch or a specification and the team will work it out.

Small and Sample Orders

Small order quantities and sample orders are accepted, with OEM and ODM production available.

Export Experience

Most products carry CE, ROHS, PSE, SAA and ETL approval and are exported to more than 30 countries and regions.

Frequently Asked Questions

What Is the Model Number of ARC Magnetic Track Flood Light?

The item number is SC-ARF-02.

What Power Options Are Available for ARC Magnetic Track Flood Light?

Available power: 16W.

What Are the Dimensions of ARC Magnetic Track Flood Light?

The dimensions are L360XW22XH25mm.

What Input Voltage Does ARC Magnetic Track Flood Light Work On?

It works on AC85-265V.

What Is the Output Voltage?

The output voltage is DC48V.

Can This Product Be Customised?

Yes. Seven Colors Lighting states that customising is available for any product and that items can be made to your design, drawing or idea.

Do You Accept Small Orders and Sample Orders?

Yes. Seven Colors Lighting accepts small orders and sample orders, along with OEM and ODM work, and states that small order quantities can still get a good price.

Which Approvals Do Your Products Carry?

According to Seven Colors Lighting, most of its products have CE, ROHS, PSE, SAA and ETL approval, and are exported to more than 30 countries and regions including the USA, Japan, Australia, Canada, Italy and Germany.
