Zero sequence mini current transformer
MINI current transformer
Pin type mini current transformer
Made by Qianwei Current Transformer Co., Ltd. in Liushi, Wenzhou. Tell us the ratio, accuracy class and burden and we will confirm the exact frame, the price and the lead time.
- Category
- Current Transformers
- Series
- MINI current transformer
- Manufacturer
- Qianwei, Wenzhou China
- Certification
- ISO 9001 and CE
Technical data
Quick Details Place of Origin: Zhejiang, China (Mainland) Brand Name: QIANWEI Model Number: CT-409 Usage: Current Phase: Single Coil Structure: Toroidal, Split Core Current transformer Coil Number: Autotransformer standard: IEC60044-1 Coil Structure TYPE: mini current transformer Outer Case: PA66 70G33L E41938 Lead Wire: UL1015 22AWG 600V 105°c (L=600mm) Core: N42UU20.6 is_customized: Yes current transformer: loading type current transformer Pin type: pin type current transformer
Click to other model catalogue : MINI current transformer
Specifications
High precision current transformer
1. Small size,
2. high accuracy,
3.good consistency,
4.lower price
Features
Low cost. Low profile for PCB mounting
High accuracy, wide linear range, low phase shift error
Burn-resistant case and filler
Specifications
Accuracy Class: 0.1
Dielectric strength: 2500V/min
Dielectric Resistance: 1000M Ohms @ 500 VDC
Working frequency 50-400Hz
Ambient temperature: -25degrees~+85degrees
RoHS Compliant
CE-approved
Customer specifications are available
Application
Electronic energy meter, power transducer, precision power meter and other power and energy monitoring devices
Over current protection circuit of motor and other electrical appliances.
Click to other model catalogue : MINI current transformer
Other models in MINI current transformer
Voltage power mini transformer
MINI current transformer
combined type mini current transformer
MINI current transformer
DC immune mini current transformer
MINI current transformer
Current voltage mini transformer
MINI current transformer
Busbar type mini current transformer
MINI current transformer
Loading type mini current transformer
MINI current transformer
Questions about this model
How do I get a price for the Pin type mini current transformer
Email [email protected] or message us on WhatsApp with the model, the ratio, the accuracy class, the burden in VA and the quantity.
What is the burden and why do you ask for it
The burden is the total termination impedance seen by the transformer: the measuring instrument, the connecting leads and the winding itself. Accuracy class cannot be guaranteed without it, and long lead runs add resistance that has to be counted.
Can this model be customised
Ratios, secondary current and mounting can often be adapted within the same frame. Send us the requirement and we will confirm what the frame allows.
Ask about the Pin type mini current transformer
Give us the ratio, the accuracy class and the burden and you will get a firm model number and price.
