Busbar type mini current transformer
Made by Qianwei Current Transformer Co., Ltd. in Liushi, Wenzhou. Tell us the ratio, accuracy class and burden and we will confirm the exact frame, the price and the lead time.
- Category
- Current Transformers
- Series
- MINI current transformer
- Manufacturer
- Qianwei, Wenzhou China
- Certification
- ISO 9001 and CE
Technical data
Quick Details Place of Origin: Zhejiang, China (Mainland) Brand Name: OEM Model Number: CT-002 Usage: Current Phase: Single Coil Structure: Toroidal, Micro Precision current transformer Coil Number: Autotransformer standard: IEC60044-1 and ANSI C12.20 Color: white inner hole: 7mm Outer Case: PA66 70G33L E41938 Lead Wire: UL1015 22AWG 600V 105°c (L=600mm) Core: N42UU20.6 Electric meter current transformer: Epoxy Encapsulated transformer is_customized: Yes
(wechat)
Click to other model catalogue : MINI current transformer
Features
Meet the standard IEC60044-1 and ANSI C12.20
High accuracy class ,wide linearity
Superitor stability ,separate the external magneitc field interference
Measure the current directly
It is with the diode to save people's life
Meet the ROHS requirement
Specifications
| No. | Name | Materials /UL | ||||||||
| 1 | Core | N42UU20.6 | ||||||||
| 2 | Winding | 2UEW/130 MW75-C Φ0.16E255929 | ||||||||
| 3 | Outer Case | PA66 70G33L E41938 | ||||||||
| 4 | Lead Wire | UL1015 22AWG 600V 105°c (L=600mm) | ||||||||
| 5 | Diode | IN4738A 1W | ||||||||
(wechat)
Click to other model catalogue : MINI current transformer
Other models in MINI current transformer
Zero sequence mini current transformer
MINI current transformer
Voltage power mini transformer
MINI current transformer
combined type mini current transformer
MINI current transformer
DC immune mini current transformer
MINI current transformer
Current voltage mini transformer
MINI current transformer
Loading type mini current transformer
MINI current transformer
Questions about this model
How do I get a price for the Busbar type mini current transformer
Email [email protected] or message us on WhatsApp with the model, the ratio, the accuracy class, the burden in VA and the quantity.
What is the burden and why do you ask for it
The burden is the total termination impedance seen by the transformer: the measuring instrument, the connecting leads and the winding itself. Accuracy class cannot be guaranteed without it, and long lead runs add resistance that has to be counted.
Can this model be customised
Ratios, secondary current and mounting can often be adapted within the same frame. Send us the requirement and we will confirm what the frame allows.
Ask about the Busbar type mini current transformer
Give us the ratio, the accuracy class and the burden and you will get a firm model number and price.
