High Flow Filter Housings

SCV & SCH series high flow stainless steel filter housings are designed to accept PALL,3M, Parker, Harmsco and other brand high flow pleated filter cartridges. The housings are available in both vertical and horizontal. ODM is available once filter cartridge dimension provided.

high flow filter housings

High flow filter housing

SS housing

Features

Design for various brand high flow filters
Accept 20″, 40″ and 60″ high flow filters
Vertical and horizontal offered
Save cost for filter use, labor, and footprint

Applications

Pre-RO, Desalination
Chemical, Oil
Ink/paints/coatings
Power
Coolants
Food and beverage

Specifications

Inlet/outlet: Flange
Finish: polished or sand blast

Materials of Construction

Housings: 304, 316L
O-ring: Buna, Silicone, EPDM, Viton

Operating Parameters

Max. Pressure: 150 psi (10 bar)
Max. Temperature: 150 ℃

Ordering Information e.g.: SCH-5-40-S4-5-B

Code

Nos of Filter

Length

Material

Inlet/Outlet

O-rings

SCV=Vertical

SCH=Horizontal

…

20”

40”

60”

S4=SS304

S6=SS316L

2”

3”

4”

…

10”

B=Buna

E=EPDM

S=Silicone

V=Viton

FAQ

Questions About This Product

Will this fit my existing housing

Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.

Which micron ratings and lengths are available

Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.

What is the production capacity

Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.

Which industries is this used in

Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.
