HFSW Series High Flow Filter Cartridges
HFSW Series High Flow Filter Cartridges HFSW series high flow cartridge filters are designed for removal of suspended iron oxide, copper, and other particles for power plant condensate water. The continuous yarn forms graded density.
- Supplier
- Shanghai Liquapure Filtration Co., Ltd, Shanghai, China
- Customisation
- Micron rating, length and end cap specified to your housing
- Photographs on file
- 1
Details
Full Description
HFSW Series High Flow Filter Cartridges
HFSW series high flow cartridge filters are designed for removal of suspended iron oxide, copper, and other particles for power plant condensate water. The continuous yarn forms graded density structure for depth filtration, and it also avoid fiber release. Powdered resin can be precoated for better backwash and filter life.
Power plant filter
Features
SS core for high strength
Continuous yarn, no fiber release
Back washable
Threaded adapter for easy installation
Applications
Power station
Steel plant
Desalination
Chemicals
Dimensions
Outer Diameter: 50mm, 60mm
Length: 50”,60”,70”,80”
Materials of Construction
Core: SS304, SS316L
Media: Polypropylene, Cotton
Operating Parameters
Max. Temperature: 80℃
Max. Differential Pressure: 2.5 bar
Ordering Information e.g.: HFSW-5-70-50-T15-M10
| Code | Micron | Length | OD | Bottom Adapter | Top Adapter |
| HFSW | 1
5 10 20 |
50”
60” 70” 80” |
50mm
60mm |
T15=M33X1.5
T20=M33X2 G1=G1” |
M8
M10 M6 |
FAQ
Questions About This Product
Will this fit my existing housing
Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.
Which micron ratings and lengths are available
Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.
What is the production capacity
Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.
Which industries is this used in
Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.
How do I get a quotation
Call +86 137 6415 7715 with the specification and the quantity you need.
