HFPP Series High Flow Cartridge Filters
HFPP Series High Flow Cartridge Filters HFPP series high flow cartridge filters are designed especially for power station condensation water filtration. The pleated structure maximum the surface area for high flow rate and back washable..
- Supplier
- Shanghai Liquapure Filtration Co., Ltd, Shanghai, China
- Customisation
- Micron rating, length and end cap specified to your housing
- Photographs on file
- 1
Details
Full Description
HFPP Series High Flow Cartridge Filters
HFPP series high flow cartridge filters are designed especially for power station condensation water filtration. The pleated structure maximum the surface area for high flow rate and back washable. Various adapters are available for customer’s existing housings.
power plant filter cartridges
Filter cartridges for Power Plant
Features
- High filtration area, high flow rate
- Back washable
- High strength
- Easy installation
Applications
- Power station
- Steel plant
- Desalination
- Chemicals
Dimensions
- Outer Diameter: 64mm, 68mm
- Length: 50”,60”,70”
Materials of Construction
- Core/Cage: Polypropylene
- Media: Polypropylene
- O-rings: EPDM, Buna, Silicone
Operating Parameters
- Max. Temperature: 80℃
- Max. Differential Pressure: 2.8 bar @ 65℃
- Design flow rate: 3.5~5 m³/h per 70”
Ordering Information e.g.: HFPP-10-70-68-2
| Code | Micron | Length | OD | Adapter |
| HFPP | 1
2 4 5 10 |
50”
60” 70” |
64mm
68mm |
T=Thread
2-222/fin |
FAQ
Questions About This Product
Will this fit my existing housing
Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.
Which micron ratings and lengths are available
Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.
What is the production capacity
Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.
Which industries is this used in
Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.
How do I get a quotation
Call +86 137 6415 7715 with the specification and the quantity you need.
