HFPL Series High Flow Filter Cartridges

HFPL Series High Flow Filter Cartridges

HFPL series high flow cartridge filters with 6” diameter and length up to 60” adopt microfiber PP or Fiberglass as filtration media with high flow capacity. Standard coreless, single open, and inside-out flow direction structure ensure the filter retain contaminant even during change-out. With the same flow capacity, high flow filters take less footprint than traditional sediment filters and pleated filters, also it is easy and cost effective for saving time and labor during change-out.

Pall high flow filter

SS high flow filter cartridges

SS high flow filter cartridge

Features

• Large Diameter pleated type for high flow rate
• Multi-layer structure for high flow efficiency & safety.
• Max 500GPM in a single 60” cartridge

Applications

• Pre-RO
• Desalination
• Chemicals
• Beverage and Food
• Cooling water

Dimensions

• Outer Diameter: 6” (152mm)
• Length: 10”, 20”, 40”, 60”,

Materials of Construction

• Core/Cage: Polypropylene
• Media: Polypropylene, Fiberglass
• O-rings: EPDM, Buna, Silicone, viton

Operating Parameters

• Max. Temperature: PP 80℃, Fiberglass 130℃
• Max. Differential Pressure: 3.5 bar @ 21℃
• Recommend Change-out：2.4 bar
• Max. Flow Rate: 40”@75 m³/h, 60”@113 m³/h
• Recommend Flow Rate: 40”@33m³/h, 60”@50 m³/h

Ordering Information e.g.: HFPL-5-40-P-N-B-E

Code	Micron	Length	Media	Core	Cage	O-rings
HFPL	1 5 10 20 50	10” 20” 40” 60”	P=PP F=Fiberglass M=Meltblown	N=None P=PP S=SS304	P=PP Cage S=PP Sleeve B=Bandage S=SS304	B=Buna E=EPDM S=Silicone V=Viton
