HFMH Series High Flow Filter Cartridges

HFMH Series High Flow Filter Cartridges

HFMH series high flow cartridge filters with 6.5” diameter and length up to 60”. The single piece filter media, radial pleated technology Maximize the filtration area within certain filter length. This structure enlarges the dirt holding capacity, extend the service life and save cost.

High flow filter

Features

• Horizontal pleated technology
• Superior filtration area for high flow rate
• High dirt holding capacity for long life and efficiency
• Less footprint, easy change-out

Applications

• Pre-RO
• Desalination
• Chemicals
• Beverage and Food
• Cooling water

Dimensions

• Outer Diameter: 6.5” (165mm)
• Length: 10”, 20”, 40”, 60”,

Materials of Construction

• Core/Cage: Polypropylene
• Media: Polypropylene
• O-rings: EPDM, Buna, Silicone, Viton

Operating Parameters

• Max. Temperature: 80℃
• Max. Differential Pressure: 3.5 bar @ 21℃
• Recommend Change-out：2.4 bar
• Max. Flow Rate: 40”@72 m³/h, 60”@110 m³/h
• Recommend Flow Rate: 40”@35m³/h, 60”@52 m³/h

Ordering Information e.g.: HFMH-5-40-E-S

Code	Micron	Length	O-rings	Adapter
HFMH	1 5 10 20 50	10” 20” 40” 60”	B=Buna E=EPDM S=Silicone V=Viton	D=Round Type Double O-ring S=Claw Type Single O-ring
