3M Equivalent Vertical pleated design filter cartridges

3M Equivalent Vertical pleated design filter cartridges with 6.5” diameter and length up to 60”. It is designed with inner core and injection mold outer cage for outside-in flow pattern and high strength. Compared with traditional cartridge filtration system, it take less footprint, easy change-out for cost saving purpose.

3M high flow filtration

Features

• Vertical pleated design

• High dirt holding capacity, long service life

• Large filtration area, high flow rate

• Less footprint, easy change-out

Applications

• Pre-RO

• Desalination

• Chemicals

• Beverage and Food

• Cooling water

Dimensions

• Outer Diameter: 6.5” (165mm)

• Length: 10”, 20”, 40”, 60”,

Materials of Construction

• Core/Cage: Polypropylene

• Media: Polypropylene

• O-rings: EPDM, Viton, Buna, Silicone

Operating Parameters

• Max. Temperature: 80℃

• Max. Differential Pressure: 3.5 bar @ 21℃

• Recommend change-out：2.4 bar

• Max. Flow Rate: 40”@80 m³/h, 60”@115 m³/h

• Recommend Flow Rate: 40”@38m³/h, 60”@65 m³/h

Ordering Information e.g.: HFMV-5-40-E-S

_____________________________________________________________________________________________________________________________________

Code	Micron	Length	O-rings	Adapter
HFMV	1 5 10 20 50	10” 20” 40” 60”	B=Buna E=EPDM S=Silicone V=Viton	D=Round Type Double Oring S=Claw Type Single Oring
