HFDD Series High Flow Filter Cartridges
HFDD series high flow cartridge filters are designed with 180mm diameter, and the media are available with both PP melt blown and membrane. With high filtration efficiency and service life, the graded density melt blown ensure a better dirt holding capacity and pleated type offer large surface area and flow capacity.
high flow filter housings
Features
High flow rate, less footprint
Cost effective for change-out
Graded density structure for long filter life
Applications
Pre-RO
Desalination
Chemicals
Beverage and Food
Cooling water
Dimensions
Outer Diameter: 7” (180mm)
Length: 40”
Materials of Construction
Core/Cage: Polypropylene
Media: PP, PET
O-rings: EPDM, Buna, Silicone, viton
Operating Parameters
Max. Temperature: PP 75℃
Max. Differential Pressure: 2.4 bar @ 21℃
Recommend change-out：1.5 bar
Max. Flow rate: Pleated@110m³/h, Meltblown@70m³/h
Recommend Flow Rate: Pleated@70m³/h, Meltblown@50m³/h
Ordering Information e.g.: HFDD-5-40-P-E
| Code | Micron | Length | Media | O-rings |
| HFDD | 1
5 10 20 50 |
40”
|
P=PP
M=Meltblown |
B=Buna
E=EPDM S=Silicone V=Viton |
FAQ
Questions About This Product
Will this fit my existing housing
Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.
Which micron ratings and lengths are available
Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.
What is the production capacity
Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.
Which industries is this used in
Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.
How do I get a quotation
Call +86 137 6415 7715 with the specification and the quantity you need.
