HFHT Series High Flow Filter Cartridges

HFHT Series High Flow Filter Cartridges HFHT series high flow cartridge filters are designed for high flow, high temperature, and high pressure filtration need. With diameter 150mm, and length 1030mm, single filter can achieve max. 70m³/h.

Range: High Flow Filter Cartridges
Type: Others high flow filter cartridges
Supplier: Shanghai Liquapure Filtration Co., Ltd, Shanghai, China
Customisation: Micron rating, length and end cap specified to your housing
Photographs on file: 1

Call +86 137 6415 7715 Contact Details

Details

Full Description

HFHT Series High Flow Filter Cartridges

HFHT series high flow cartridge filters are designed for high flow, high temperature, and high pressure filtration need. With diameter 150mm, and length 1030mm, single filter can achieve max. 70m³/h flow capacity.

filter cartridges water treatment

Features

Multi-layer graded density structure
High flow rate for single piece
Save footprint for system design

Dimensions

Outer Diameter: 6” (150mm)
Length: 40” (1030mm)

Materials of Construction

Core/Cage: Polypropylene
Media: Polypropylene, Fiberglass
O-rings: EPDM, BNR

Operating Parameters

Max. Temperature: PP 82℃, Fiberglass 130℃
Max. Differential Pressure: 3.5 bar @ 21℃
Recommend Change-out：2.4 bar
Max. Flow Rate: 40”@70 m³/h
Recommend Flow Rate: 40”@35m³/h

Ordering Information e.g.: HFHT-5-40-P-N-B-E

Code

Micron

Length

Media

O-rings

HFHT

10,

40”

P=PP

F=Fiberglass

B=Buna

E=EPDM

S=Silicone

V=Viton

FAQ

Questions About This Product

Will this fit my existing housing

Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.

Which micron ratings and lengths are available

Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.

What is the production capacity

Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.

Which industries is this used in

Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.

How do I get a quotation

Call +86 137 6415 7715 with the specification and the quantity you need.
