HFBH Series High Flow Filter Cartridges

HFBH series high flow cartridge filters are designed with 6” diameter and suitable for #1 and #2 bag filter housings. The inside-out flow pattern traps the contaminant even during changeout without pollution of filtrated liquid.

Bag filter cartridges

Features

High strength than bag filter
Wide chemical compatibility
Graded density structure for depth filtration

Applications

Oil and Gas
Chemicals
Paint
Pre-RO

Dimensions

Outer Diameter: 6” (152mm)
Length: 16”, 32”

Materials of Construction

Core/Cage: Polypropylene
Media: Polypropylene
O-rings: EPDM, Buna, Silicone

Operating Parameters

Max. Temperature: 80℃
Max. Differential Pressure: 3.5 bar @ 21℃
Recommend change-out：2.4 bar

Ordering Information e.g.: HFBH-5-32-B

Code

Micron

Length

O-rings

HFBH

16”

32”

B=Buna

E=EPDM

S=Silicone

V=Viton

FAQ

Questions About This Product

Will this fit my existing housing

Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.

Which micron ratings and lengths are available

Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.

What is the production capacity

Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.

Which industries is this used in

Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.

How do I get a quotation

Call +86 137 6415 7715 with the specification and the quantity you need.
