Sintered Titanium Filter Cartridges STF series sintered titanium filter cartridge is made of 99.4% purity titanium metal powder which is suitable for corrosive liquids and gases, cryogenic fluids, high viscosity solutions, process steam,.
- Range
- Filter Cartridges
- Supplier
- Shanghai Liquapure Filtration Co., Ltd, Shanghai, China
- Customisation
- Micron rating, length and end cap specified to your housing
- Photographs on file
- 1
Details
Full Description
Sintered Titanium Filter Cartridges
STF series sintered titanium filter cartridge is made of 99.4% purity titanium metal powder which is suitable for corrosive liquids and gases, cryogenic fluids, high viscosity solutions, process steam, high temperature liquids and gases and catalyst recovery. Especially for decarburizing filtration and ozone water.
sintered Titanium Filter
Features
- Corrosion resistance
- Ozone resistance
- Cleanable and reusable
- High dirt holding capacity
Dimensions
- Outer Diameter: 30mm, 50mm, 60m
- Length: 70mm, 125mm
Operating Parameters
- Max. Temperature: 280 ℃
- Max. Differential Pressure: 3 bar@21℃
Ordering Information e.g.: STF-1-10-M2-E
| Code | Micron | Length | Adapter | O-ring |
| STF | 0.45
1 3 5 10 |
5”
10” 20” 30” 40” |
0=DOE
2=226/flat 3=222/flat M2=M20 M3=M30 |
B=Buna
E=EPDM S=Silicone V=Viton T=PTFE Encapsulated |
FAQ
Questions About This Product
Will this fit my existing housing
Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.
Which micron ratings and lengths are available
Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.
What is the production capacity
Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.
Which industries is this used in
Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.
How do I get a quotation
Call +86 137 6415 7715 with the specification and the quantity you need.
