Pure Sine Wave Inverter
Pure sine wave and modified sine inverters and solar DC surge protection.
| Category | Solar and Inverters |
| Type | Pure Sine Wave Inverter |
| Manufacturing | OEM to customer design, ISO9001 and ISO14001 |
YPS-300 Pure Sine Wave Power Inverter
Product Name: 300W Pure Sine Wave Power Inverter
Country of Origin: China
Model: YPS-300
Color: Silver
Minimum order: 300 pieces
Delivery Lead Time: 40 Days
Delivery FOB port: China Ningbo Port
Payment Condition: T/T
Continue Power: 300 W
Max. Output Surge: 600 W
DC Input Voltage: 12V or 24V or 36v or 48V
AC Output Voltage: 110V or 120V or 220V or 230V or 240V
Dimensions (mm): (180+25) x 112 x 58
Weight (kg): 1.25 kg
Digital microprocessor design.
Short circuit alarm and protection
Overload alarm and protection
Reverse polarity protection
Intelligent over temperature alarm and shutdown
High and low battery voltage alarm and shutdown
Intelligent disperses heat system
High surge capacity for starting demanding loads
Stable output voltage and frequency
Low no load current draw
Advanced SMT technology
Pure Sine Wave Output
Computers, medical instruments, cash registers, TVs, DVD players, audio equipment, fax machines, limousines, buses, RVs, air-pumps, various types of light duty motors, etc.
| ‧ YPS-300 Specifications: |
|---|
| Model | YPS-300-12 | YPS-300-24 | YPS-300-36 | YPS-300-48 | ||
|---|---|---|---|---|---|---|
| Output | Continuous output | 300W | ||||
| Surge Power | 600W | |||||
| AC Voltage | 100V / 110V / 115V / 120V / 200V / 220V / 230V / 240V to be selected | |||||
| Regulation | Vrms ±3% | |||||
| Frequency | 50Hz or 60Hz | |||||
| Wave Form | Pure Sine Wave | |||||
| Total Harmonic Distortion | THD ＜3 % | |||||
| Input | BatteryVoltage | 12V | 24V | 36V | 48V | |
| DC Current (typ.) | 30A | 15A | 10A | 7.5A | ||
| Low Battery Alarm | 10.5V ± 2% | 30V ± 2% | 31.5V ± 2% | 42V ± 2% | ||
| BatteryVoltage Selected | 10V ±2% | 20V ± 2% | 30V ±2% | 40V ±2% | ||
| High Battery | 16V ± 2% | 32V ± 2% | 48V ± 2% | 64V ± 2% | ||
| No load current | 400mA | 250mA | 130mA | 100mA | ||
| Efficiency | 87% | |||||
| Protection | High temperature | Yes | ||||
| Short-circuit | Yes | |||||
| Overload | Yes | |||||
| Input Voltage | Yes | |||||
| Mains / inverter converter | 0.2S | |||||
| Intelligent Design Heat Auto Control | Fan Start : 42℃ ± 3 , Fan Stop : 38℃ ± 3 | |||||
| High Temperature Shut Down : 70℃ ±3 , Restart Output : 55℃±3 | ||||||
| Mechanical | Dimensions(mm) | 180+25(D) x 95 (W) x 55 (H) | ||||
| Weight | 1.25 kg | |||||
Model
Output
Continuous output
Surge Power
AC Voltage
100V / 110V / 115V / 120V / 200V/ 220V / 230V / 240V to be selected
Regulation
Vrms ±3%
Frequency
50Hz or 60Hz
Wave Form
Pure Sine Wave
Total Harmonic Distortion
Input
BatteryVoltage
DC Current (typ.)
Low Battery Alarm
BatteryVoltage
Selected
High Battery
No load current
400mA
250mA
130mA
100mA
Efficiency
87%
Protection
High temperature
Yes
Short-circuit
Yes
Overload
Yes
Input Voltage
Yes
Mains / inverter converter
Intelligent Design Heat Auto Control
Fan Start : 42℃± 3 , Fan Stop : 38℃± 3
High Temperature Shut Down : 70℃±3 , Restart Output : 55℃±3
Mechanical
Dimensions(mm)
180+25(D) x 95 (W) x 55 (H)
Weight
FAQ
Email [email protected] with the product name, the rating and the accuracy class you need and the quantity.
Yes. Everfar is distinguished by OEM manufacture and develops customers' designs.
Everfar is qualified to ISO9001 and ISO14001, and holds product certificates including CE, UL and KEMA.
Send the rating and the quantity and our sales team will confirm the price.
