Metallic Substrate
Honeycomb Metallic Substrate
Honeycomb Metallic Substrate
Drawings and CAD files on request — email them to [email protected] and we will quote against your print.
Product Overview
DEFERRY®'s metallic substrate is using 0.06mm,0.05mm or thinner steel foil in the series of products, this leads to a further reduction in the exhaust gas counter pressure which improves the engine performance and decrease the fuel consumption.
Current product offer covers from 0.5" to 39.5" in diameter as a single catalyst for 3-way, DOC, VOC and other industrial applications, which would be perfect solution for gasoline or diesel engines displacement from 0.1 to 35 liters,the diameter and height can be designed according to customer requirements.
The Product Highlights of DEFERRY®'s Metallic Substrate
- Material SUS304, SUS441 or as customer requirement
- Density: can be From 100CPSI to 1000CPSI
- Meet the emission legislation for the Euro III,small engine:EPA CARB &Emark, diesel engine: Euro IV,Euro Euro V.
- Specification: can be designed as customer needed. Especially,we have large specification metallic substrate for the for diesel engine truck which can meet the emission standard of Euro V,Euro VI etc.
- We have our advantage product of double SS foil metallic substrate: Faster conduction heat (disparate the heat faster, the foil is not easy to melted). Higher vacuum intention the foil material will be brazed much faster which wont be loosed when the metallic substrate is used. The double S have much better purification efficiency.
Questions About This Product
Can the size be made to our drawing?
How do I get a price?
Is Deferry certified?
Quote Metallic Substrate
Send the quantity and either the dimensions or the OE number. We reply with specification, lead time and price.
