Anchor Clamp

PINZA AJUSTABLE PARA ACOMETIDA PA

PINZA DE RETENCION DOBLE Material cuerpo: Termoplástico con protección con protección a los rayos ultra violeta (UV),Carga de rotura mínima: 250 daN

  • The PA service clamp is designed to protect the concentric rush conductor avoiding its start accidental, works in conjunction with the connection bracket and facade CROP brand, accepts ranges of 2x4mm2 up to 4x25mm2. Mechanical strength greater than 205Kg – F, making it ideal for crossing streets and groves, without putting at risk the preassembled network, the PA has an angle of 15 degrees what facilitates the installation and operation for the workers of the electric companies.
  • Más detalles, consulte nuestro sitio web en español: www.imcrop.com
Request A Quote Email Us Request A Sample
GroupABC Accessories
CategoryAnchor Clamp
StandardsIEC and GB
CustomisationOEM and non standard accepted
PINZA AJUSTABLE PARA ACOMETIDA PA
OverviewGalleryOrderingFAQRelated

Overview

PINZA AJUSTABLE PARA ACOMETIDA PA Description

PINZA DE RETENCION DOBLE

Más Detalles, Consulte Nuestro Sitio Web En Español: Www.imcrop.com

Descripción of PINZA DE RETENCION DOBLE

PINZA DE RETENCION DOBLE modelo PA esta diseñada para proteger al conductor concéntrico de acometida evitando su arranque accidental, funciona en conjunto con la ménsula de acometida y fachada marca CROP, acepta rangos de 2x4mm2 hasta 4x25mm2. Fuerza mecánica superior a 205Kg – F, haciendola ideal para realizar cruces de calles y arboledas, sin poner en riesgo la red preensamblada, la PA posee un angulo de 15 grados lo que facilita la instalación y operación para los trabajadores de las empresas eléctricas.

Fabricante: CROP

Modelo: AC-PAG25,AC-PA25

País de origenS: China

Norma de fabricación y ensayos: ASTM G 26

Características

Material cuerpo: Termoplástico con protección con protección a los rayos ultra violeta (UV)

Material cuña: Termoplástico con protección a los rayos ultra violeta (UV)

Material del gancho: Acero inoxidable resistente a los efectos provocado por el medio ambiente, salinidad, humedad y cambio atmosférico

Apta para conductores: Concéntricos y ovalado de acometida

Carga de rotura mínima: 250 daN

Deslizamiento mínimo: 180 daN

Sección mínima del conductor a sujetar: 2x #10 AWG

Sección máxima del conductor a sujetar: 3x #4 AWG

Propiedades Eléctricas

Tensión nominal: 600 V

Rigidez diélectrica: ＞6KV

Rango Sujeción

Cable Acometida: Desde 2X4 mm2 Hasta 4×25 mm2

Propiedades Físicas

Plástico cuerpo: Termoplástico (poliamida) reforzado con FV y UV

Cuña: Termoplástico (poliamida) reforzado con FV y UV

Amarre: Acero inoxidable de alta resistencia

Taracción max: 205 kgf

Carga de trabajo: 40,78 – 122,36 kgf

Color: Negro con protección UV
