Piercing Connector
Зажим ответвительный прокалывающий PCT13C 120/10
Зажим ответвительный прокалывающий предназначен для герметичного соединения и ответвления изолированных абонентских проводов и проводников освещения.
- Insulation Piercing Connector PCT13C Function: Tap a small wire off of a large wire A convenient and fast way to safely and securely tap off of an existing line. You can tap off of the middle a line that is from #6 gauge wire to 4/0 cable to feed a 14 AWG to #10 awg wire. You do not have to cut or interrupt the main line. Install with the power shut off to the main line. Standard: IEC 61284, EN 50483, IRAM2435, NFC33 020.
GroupABC Accessories
CategoryPiercing Connector
StandardsIEC and GB
CustomisationOEM and non standard accepted
Overview
Зажим Ответвительный Прокалывающий PCT13C 120/10 Description
Зажим Ответвительный Прокалывающий
Полное Описание
- Контактные пластины: луженая латунь
- Cрывная головка: алюминий
- Метизы: сталь с гальваническим покрытием
- Корпус: пластик, стойкий к воздействию ультрафиолета и отрицательным температурам
Related Product
Specifications
Codes Ranges and Dimensions
Figures below are reproduced from the CROP catalogue for this item.
| Models | PCT13C 120/10 | PCT13CB 120/10 |
|---|---|---|
| Main Line(mm²) | 6-120 | 6-120 |
| Service Line (mm ² ) | 1.5-10 | (B) 1.5-10 |
| Bolt No. | 1 | 1 |
| Torque (Nm) | 10NM | 10NM |
| Remarks | ISO to ISO | ISO to Bare |
| Models | PCT13C 70/35 | PCT13C 95/50 | PCT13C 120/25 | PCT13C 150/50 | PCT13C 185/35 | PCT13CB 70/35 | PCT13CB 95/50 |
|---|---|---|---|---|---|---|---|
| Main Line(mm²) | 16-70 | 16-95 | 25-120 | 50-150 | 50-185 | 16-70 | 16-95 |
| Service Line (mm²) | 4-35 | 4-50 | 6-25 | 4-50 | 6-35 | (B)4-35 | (B)4-50 |
| Bolt No. | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| Torque (Nm) | 15NM | 17NM | 17NM | 17NM | 17NM | 15NM | 17NM |
| Remarks | ISO to ISO | ISO to ISO | ISO to ISO | ISO to ISO | ISO to ISO | ISO to Bare | ISO to Bare |
| Models | PCT13C 95/95 | PCT13C 150/150 | PCT13CB 95/95 | PCT13CB 150/150 |
|---|---|---|---|---|
| Main Line(mm²) | 16-95 | 16-150 | 16-95 | 16-150 |
| Service Line (mm²) | 16-95 | 16-150 | (B)16-95 | (B)16-150 |
| Bolt No. | 1 | 1 | 1 | 1 |
| Torque (Nm) | 17-23NM | 23NM | 23NM | 23NM |
| Remarks | ISO to ISO | ISO to ISO | ISO to Bare | ISO to Bare |
