Lugs and Joints

Copper Lugs DTG Series

CABLE LUG (DTG) Description Connecting terminals are suitable for the wire in distribution equipment and the electrical equipment. DL series

CABLE LUG (DTG) Description Connecting terminals are suitable for the wire in distribution equipment and the electrical equipment. DL series

Request A Quote Email Us Request A Sample

GroupPower Connectors

CategoryLugs and Joints

StandardsIEC and GB

CustomisationOEM and non standard accepted

Overview Specifications Gallery Ordering FAQ Related

Overview

Copper Lugs DTG Series Description

CABLE LUG (DTG)

Description Connecting terminals are suitable for the wire in distribution equipment and the electrical equipment. DL series are made by L3 aluminum bar. DT series are made of by T2 copper bar.

Related Product

Specifications

Codes Ranges and Dimensions

Figures below are reproduced from the CROP catalogue for this item.

Model	Ø	D(mm)	d(mm)	A(mm)	L3(mm)	L(mm)	L1(mm)
DTG-16	Ø8.2	9	6	128	25	80	29
DTG-25	Ø8.2	10	7	14.1	25	85	32
DTG-35	Ø8.2	11	8	15.4	25	90	33
DTG-50	Ø8.2	13	10	18.8	25	99	37
DTG-70	Ø12.5	16	12	22.5	35	120	43
DTG-95	Ø12.5	18	14	26	35	125	45
DTG-120	Ø14.5	20	15.2	29	35	134	50
DTG-150	Ø14.5	22	17	31.7	35	139	52
DTG-185	Ø14.5	24	19	34.4	35	150	60
DTG-240	Ø16.5	26	21	37.7	45	160	70
DTG-300	Ø16.5	30	24	43.4	45	164	75
DTG-400	Ø16.5	4	27	49	60	180	80
DTG-500	Ø20.5	38	30	55.5	60	225	90
DTG-630	Ø20.5	45	35	64.7	60	235	105

Product Images

Ordering and Support

From Enquiry To Delivered Order

Send The Requirement

Item code, conductor or cable size and quantity, or a drawing and a photograph for a non standard part.

Quotation

Price, packing, carton quantity and lead time are confirmed against the catalogue reference.

Sample or Tooling

Samples are sent for approval. Parts that need a new mould go through the in house mould division.

Production and Shipment

Production to IEC and GB standards, then packing and shipment on the agreed terms.

Answers

Frequently Asked Questions

How do I choose the right size?

Match your conductor or cable size against the range column in the specification table on this page, then quote the code on that row. If the size falls between two rows, send both figures with your enquiry and the correct item will be confirmed.

Is Copper Lugs DTG Series available as a sample before a production order?

Yes. Ask for a sample by WhatsApp on 0086 138 6832 9796 or by email and the item, the packing and the lead time for a full order will be confirmed together.

Which standards do CROP products follow?

All CROP products are made to comply with IEC and GB standards. Where a project calls for a national or utility specification, send the standard reference with your enquiry and the matching item will be quoted.

Can items be produced to our own drawing?

Yes. Non-standard and OEM orders are part of the normal range. Send the drawing, a picture, the weight or the written specification to [email protected] or by WhatsApp and a quotation will be prepared against your requirement. CROP also runs its own mould division for plastic, SMC and stamped parts.

How do I obtain the PDF catalogue?

The catalogue is issued on request. Ask for the section you need by email or WhatsApp on 0086 138 6832 9796 and the PDF will be sent back to you. The catalogue page lists every section that is available.
