Punch Press

Electric Screw Press Machine

Presses cover hydraulic, pneumatic and CNC stamping machines used for blanking, piercing and forming of sheet metal parts.

Built by Ningbo Anchors Precision Machinery Co., Ltd. in Ningbo, China
Full manufacturer parameter table on this page
Machine video available on request
Rapid response technical team for operation and troubleshooting

Request a Quote Talk to an Engineer Email Us

Have a drawing? Send it straight to WhatsApp or email — there is no form to fill in.

Electric Screw Press Machine Specifications

Model	Unit	7B-3S	10B-3S	10B-3SL	13B-3S	13B-3SL	17B-3S	17B-3SL	19B-3S	19B-3SL	24B-3S	24B-3SL	30B-3S	33B-3S	36B-3S	41B-3S
Forging Stations	Pcs	Three	Three	Three	Three	Three	Three	Three	Three	Three	Three	Three	Three	Three	Three	3
Forging Force	Ton	15	28	30	50	50	70	70	90	90	160	160	220	260	320	450
Max. Material Cutting Diameter	Mm	5	8	8	10	10	12	12	15	15	18	18	23	26	29	34
Max. Material Cutting Length	Mm	55	70	105	94	130	105	180	140	185	185	270	270	300	320	400
K.O Length	Mm	45	60	90	76	120	90	175	120	180	145	230	230	260	290	340
P.K.O Length	Mm	10	13	20	17	23	22	30	26	30	33	36	35	45	60	60
Cutting Die Size	Mm	20*30	28*46	28*46	35*56	38*79	40*66	40*80	46*80	46*80	60*100	60*120	75*120	84*130	90*140	110*140
Main Die Size	Mm	38*60	50*65	50*105	60*85	70*135	70*95	80*185	80*123	93*190	100*195	100*240	125*240	140*280	160*294	178*385
Die Pitch	Mm	48	60	60	87	87	93	93	114	114	126	126	138	156	174	195
Punch Die Size	Mm	32*60	40*80	40*110	45*90	45*111	50*102	50*130	60*120	60*170	75*160	75*200	90*190	96*210	105*232	120*250
Suitable Bolt & Screw Size		M2-M4	M3-M6	M3-M6	M6-M8	M6-M8	M8-M10	M8-M10	M10-M12	M10-M12	M12-M16	M12-M16	M16-M20	M16-M22	M20-M24	M24-M27
Max. Product Length	Mm	40	50	75	65	100	75	150	100	150	150	200	200	225	250	300
Min. Product Length	Mm	10	12	16	14	20	16	30	20	40	25	50	40	50	60	80
Max. Production Speed	Pcs/Min.	300	300	240	240	210	210	175	170	125	120	100	90	75	60	50
Main Motor Power	Kw	5	11	15	15	15	15	22	30	38	55	55	75	90	90	130
Appro. Machine Weight	Ton	3.5	6	7.5	9	11.5	13	17	20	22	36	40	52	70	90	130

Electric Screw Press Machine Applications and Features

Application:Electric screw press refers to the general name of the pressure machine formed by rotating more than one set of outer bolts and inner bolts in the frame, and the synchronous servo CNC electric screw press cancels the double vertical wheel assembly of the traditional friction press , Direct servo motor drive, reduce energy loss, no energy loss when loading, discharging, and cleaning mold during blow molding, saving power 55%, one-click operation can complete the whole blow process, reduce helpers, simplify Management, safe and energy-saving, is an updated product of the double-disc friction press.It can be adapted to hot forging, precision forging and finishing; at the same time, it is suitable for the welding process of stainless steel double-bottom pot, precision forging of titanium alloy blade or other blades. It is an indispensable advanced equipment for modern forging enterprises.

This machine has the characteristics of strong anti-eccentric load capacity, small mold stress, long life, high forging forming accuracy, etc. It is superior to traditional screw presses in energy saving and precise control of strike force, and is suitable for die forging, precision forging, correction, bending , Imprinting and other processes. It is an ideal precision forging equipment for industries such as trains, automobiles, tractors, ships, aviation, hardware tools, medical equipment, tableware, and refractory materials.

Features:

1. Simple and reasonable structure, short transmission chain, less maintenance work, and easy operation.
2. DC brushless motor, instantaneous start, instantaneous stop. When striking the workpiece, the motor runs and stops immediately after striking, high efficiency and energy saving.
3. The main motor runs without noise.
4. Working windows on the left and right of the frame, forging parts transfer is convenient, and it is easy to realize flow operation.

5. High precision sliding guide, circular guide rail and X-shaped guide rail, small guide rail clearance, strong anti-tilting ability, suitable for multi-mode boring and die forging, saving equipment labor costs.
6. The intelligent fault detection system ensures that electrical maintenance personnel can obtain relevant information in the shortest time.
7. The strike energy of this machine can be set accurately, it is the screw press with the highest strike accuracy. With tonnage meter protection, the energy and impact force can be easily adjusted according to the requirements of the forgings, so that the mold can withstand the best stress and the appropriate time for the mold to extend the service life of the mold.
8. Equipped with photoelectric protection device to make equipment safety performance more reliable.

Other Models in Punch Press

Same family, different size range and station count.

Hydraulic Press Machine

Punch Press

High Speed Pnumatic Press Machine

Punch Press

Plain Washer High Speed Stamping Press

Punch Press

CNC Auto Strip Feeder

Stamping Auxiliary Equipment

Progressive Stamping Die

Press Stamping Die

Plain Sheet Washer Progressive High Speed Stamping Mold

Press Stamping Die

All Punch Press All Metal Stamping Machinery How It Is Built

Questions and Answers

Electric Screw Press Machine FAQ

What is the Electric Screw Press Machine used for?

It belongs to the punch press family. Presses cover hydraulic, pneumatic and CNC stamping machines used for blanking, piercing and forming of sheet metal parts. The structural description and the manufacturer parameter table on this page describe what this particular model covers.

Can I get the technical specification for my size range?

The parameter table on this page is the manufacturer table for the model range. Tell us the exact fastener diameter and length you run and we will confirm which line of the table applies.

Is this machine built by Anchors Machinery?

All equipment is built at the company works in Ningbo, Zhejiang, China, in an 18,000 square metre workshop with its own machining facilities.

Can it be supplied together with the upstream and downstream machines?

Yes. Anchors Machinery is a machine manufacturer as well as a solution provider and project contractor, so complete fastener and stamping production lines can be supplied rather than single machines only.

What support do I get after delivery?

A rapid response technical team instructs machine operation and helps solve problems that come up during production, so that machine efficiency and your output are protected after installation.

How do I request a price for this machine?

Send the part drawing or a photo plus the required size range and output per minute to [email protected] or by WhatsApp on +86 185 5689 5898. Quotations are prepared against the model and tooling configuration that suits your part.
