HK split core current transformer
Made by Qianwei Current Transformer Co., Ltd. in Liushi, Wenzhou. Tell us the ratio, accuracy class and burden and we will confirm the exact frame, the price and the lead time.
- Category
- Current Transformers
- Series
- TP Square Split Core CT
- Manufacturer
- Qianwei, Wenzhou China
- Certification
- ISO 9001 and CE
Technical data
Product Description
www.elechttp:// tricalcurrenttransformer.com
1. HK series open type current transformers are designed in Paticular for convenient installation. Don’t need open any cable or bus-bar when install.
2. The core of HK series open type current transformers can easily be opened. Installation and connection can be available without cutting off the circuitry.
3. Based on above features, open type current transformer has more advantages in adding CT after maintaining and circuitry.
Feature:
1) One button clamp-on design, safe, easy to install, portable
2) Two built in fixing methods: Base; Busbar mounting
3) Wide inner window, allowing clamping of big cables or bus-bars
4) Wide range of sizes to accommodate all the existing installations.
5) Primary current from 5A to 5000A
Application:
1) Current measurement, monitoring and protection for electrical wiring and equipment.
2) Current and power measurement for electric motors, lighting, air compressor, heating
and ventilation system, air-condition equipment and automation – control system.
3) Current, power and energy monitoring device.
4) Relay protection device.
.webp)
www.elechttp:// tricalcurrenttransformer.com
click to other model catalogue:
Other models in TP Square Split Core CT
LMZK Epoxy Resin split CT
TP Square Split Core CT
Split Core Current Transforme
TP Square Split Core CT
Questions about this model
How do I get a price for the HK split core current transformer
Email [email protected] or message us on WhatsApp with the model, the ratio, the accuracy class, the burden in VA and the quantity.
What is the burden and why do you ask for it
The burden is the total termination impedance seen by the transformer: the measuring instrument, the connecting leads and the winding itself. Accuracy class cannot be guaranteed without it, and long lead runs add resistance that has to be counted.
Can this model be customised
Ratios, secondary current and mounting can often be adapted within the same frame. Send us the requirement and we will confirm what the frame allows.
Ask about the HK split core current transformer
Give us the ratio, the accuracy class and the burden and you will get a firm model number and price.
