Custom Made Screw Loader Conveyor Feeder For Food and Chemical Industry
TheScrew Loader Conveyor Feeder is a supporting auxiliary machine required by plastic processing machinery. It can directly and automatically transport powdery or granular plastic raw materials into the hopper, or high-speed mixers, mixers and other containers. The parts that contact the raw materials are made of stainless steel. During the conveying process, the raw materials are completely free from pollution, and no foreign matter is brought into it, which can realize fully enclosed automation in the production process.
Manual charging of a high-speed mixer is slow, dusty and hard to keep on formula.
How this machine is used
Screw Loader Conveyor Feeder For Food and Chemical Industry Screw Loader Conveyor Feeding Machine Features: 1.
Screw Loader Conveyor Feeder is easy to install and movable.
If multiple mixers use the same material, only one feeder can feed multiple mixers at the same time, eliminating the trouble of manual processing and making the feeding work easier.
It is safer, more time-saving, and labor-saving.
Published specifications
| Model | ZJF300 | ZJF450 | ZJF700 |
|---|---|---|---|
| Rated conveying capacity (kg/h) | 300 | 450 | 700 |
| Rated speed(mm) | Customizable 960 | 960 Customizable | 960 or Customizable |
| Conveying spring diameter(mm) | ￠36×6 | ￠45×8 | ￠59×8 |
| Conveying distance(M) | Customizable 5 | 5 Customizable | 5 |
| Motor Power(kw | 1.1 | 1.5 | 2.2 |
Questions plants usually ask
What problem does the Custom Made Screw Loader Conveyor Feeder For Food and Chemical Industry address?
Manual charging of a high-speed mixer is slow, dusty and hard to keep on formula.
Can Prowell customize the Custom Made Screw Loader Conveyor Feeder For Food and Chemical Industry?
Yes. The source plant states equipment is 100% customizable — pot volume, impeller, motor and discharge are sized to the recipe.
How do I request a quotation?
WhatsApp or email Jarvis with material, bulk density, kg/batch or kg/hour, and any heating/cooling requirement. Use [email protected] or +86 185 5118 6172.
Are the published models the only sizes?
The tables on this page are the models printed on the original Prowell listing. Other sizes are discussed against your batch weight.
