Plastic PVC Profile Wall Panel Extrusion Making Line
PVC Profile Wall Panel is a kind of panel with a large demand for decorative wall panels in the market. It is widely used in home wall decoration. It is extruded from PVC Profile Wall Panel Extrusion Making Line, so it can be effective Instead of old-style wallpaper or wall coverings, the country’s current plastic wall panels are developing rapidly, and the overall quality of plastic panels is constantly improving.
Panel width, gloss and cut quality collapse when the profile line is assembled from mismatched units.
How this machine is used
Composition of Plastic PVC Profile Wall Panel Extrusion Making Line Extruder part: This machine has a quantitative feeding device to match the extrusion volume with the feeding volume to ensure stable extrusion of the product.
Due to the use of conical twin screws, the feeding section has a larger diameter, so the heat transfer area and shear speed of the material are relatively large, which is conducive to the plasticization of the material.
The screw diameter of the metering section is small, which reduces the heat transfer area and the opposite.
The shear speed of the melt enables the melt to be extruded at a lower temperature.
Published specifications
| Model | YF180 | YF240 | YF300 | YF600 |
|---|---|---|---|---|
| Max product width(mm) | 180 | 240 | 300 | 600 |
| Extruder model | SJZ55/110 | SJZ65/132 | SJZ65/132 | SJZ80/156 |
| Extruder power | 22 | 30/37 | 37 | 55 |
| Cooling water(m3/h) | 5 | 7 | 7 | 10 |
| Gas consumption(m3/min) | 0.2 | 0.3 | 0.3 | 0.4 |
Questions plants usually ask
What problem does the Plastic PVC Profile Wall Panel Extrusion Making Line address?
Panel width, gloss and cut quality collapse when the profile line is assembled from mismatched units.
Can Prowell customize the Plastic PVC Profile Wall Panel Extrusion Making Line?
Yes. The source plant states equipment is 100% customizable — pot volume, impeller, motor and discharge are sized to the recipe.
How do I request a quotation?
WhatsApp or email Jarvis with material, bulk density, kg/batch or kg/hour, and any heating/cooling requirement. Use [email protected] or +86 185 5118 6172.
Are the published models the only sizes?
The tables on this page are the models printed on the original Prowell listing. Other sizes are discussed against your batch weight.
