PVC Powder Granules High Speed Mixer Plastic Mixing Machine
Plastic Granules Powder Mixing Machine is a professional equipment for mixing granules and powders. The high-speed mixer is suitable for the plastics chemical industry and can also be used in the food industry.
Uneven pigment, stabilizer or plasticizer distribution shows up later as color streaks, bubbles and weak weld lines.
How this machine is used
Plastic PVC High Speed Mixing Machine Hot Mixer Powder Mixer Structural features of PVC high-speed mixer: The main components of the Plastic Granules Powder Mixing Machine are the main shaft, mixing blades, barrel, pulley, motor, frequency converter and other components.
Application range of Plastic Granules Powder Mixing Machine： The main application scenarios of the mixer are fine chemicals, feed, electronics, food, hard materials, ceramic materials, biology, medicine, non-metallic mining, building materials, coatings, dyes, fertilizers and metal powders for better mixing.
It must be carried out in accordance with the operating procedures of the equipment.
This is a good maintenance of the equipment.
Published specifications
| Model | SRL-Z100/200 | SRL-Z200/500 | SRL-Z300/600 | SRL-Z500/1000 | SRL-Z800/1600 |
|---|---|---|---|---|---|
| Total Volume (L) Hot mix/Cold mix | 100/200 | 200/500 | 300/600 | 500/1000 | 800/1600 |
| Effective volume (L) | 75/160 | 150/320 | 225/390 | 375/650 | 600/1050 |
| Stirring speed (rev/min) (rpm) | 650/130/180 | 475/950/130 | 475/950/130 | 430/860/60 | 370/740/50 |
| Heating and cooling method | self-friction | self-friction | self-friction/water cooling | Electricity, self-friction/water cooling | Electricity, self-friction/water cooling |
| Mixing time (min) | 8-10 | 8-12 | 6-10 | 6-10 | 8-12 |
| Moto Power(kw) | 14/22/7.5 | 30/42/11 | 40/50/11 | 55/75/18.5 | 60/90 |
| Size(mm) | 3780×1870×2250 | 4580×2240×2470 | 4580×2440×2570 | 4600×3000×4050 | 4850×3860×6550 |
| Weight(kg) | 3200 | 3400 | 4200 | 5800 | 8700 |
Questions plants usually ask
What problem does the PVC Powder Granules High Speed Mixer Plastic Mixing Machine address?
Uneven pigment, stabilizer or plasticizer distribution shows up later as color streaks, bubbles and weak weld lines.
Can Prowell customize the PVC Powder Granules High Speed Mixer Plastic Mixing Machine?
Yes. The source plant states equipment is 100% customizable — pot volume, impeller, motor and discharge are sized to the recipe.
How do I request a quotation?
WhatsApp or email Jarvis with material, bulk density, kg/batch or kg/hour, and any heating/cooling requirement. Use [email protected] or +86 185 5118 6172.
Are the published models the only sizes?
The tables on this page are the models printed on the original Prowell listing. Other sizes are discussed against your batch weight.
