PVC Mixer SHR-800*2/4000 Horizontal High Speed Mixing Unit
PVC Mixer SHR-800*2/4000 Horizontal High Speed Mixer Unit PVC Mixer SHR-800*2/4000 Horizontal High Speed Mixer Unit adopts a concave-convex double-channel sealing method between the container cover and the container.
Uneven pigment, stabilizer or plasticizer distribution shows up later as color streaks, bubbles and weak weld lines.
How this machine is used
PVC Mixer SHR-800*2/4000 Horizontal High Speed Mixer Unit PVC Mixer SHR-800*2/4000 Horizontal High Speed Mixer Unit adopts a concave-convex double-channel sealing method between the container cover and the container.
Compared with the traditional single-channel flat seal, the sealing effect is better.
The hot mixer blade adopts three blades or disc blades,According to customer’s different products.
The blades are dynamically balanced in order to maintain the stability of operation.
Published specifications
| Model | SRL-W300/1000 | SRL-W500/1500 | SRL-W800/2500 | SRL-W1000/3000 | SRL-W800*2/4000 |
|---|---|---|---|---|---|
| Total Volume | 300/1000 | 500/1500 | 800/2500 | 1000/3000 | 800*2/4000 |
| Effective Volume | 225/700 | 330/1000 | 600/1500 | 700/2100 | 1200/2700 |
| Stirring Paddle Speed | 475/950/80 | 430/860/70 | 370/740/60 | 300/600/50 | 350/700/65 |
| Mixing Time | 8-12 | 8-12 | 8-12 | 8-12 | 8-12 |
| Motor Power | 40/55/7.5 | 55/75/15 | 83/110/22 | 110/160/30 | 83/110*2/30 |
| Weight | 3300 | 4200 | 5500 | 6500 | 8000 |
| Output | 495 | 825 | 1320 | 1650 | 2640 |
Questions plants usually ask
What problem does the PVC Mixer SHR-800*2/4000 Horizontal High Speed Mixing Unit address?
Uneven pigment, stabilizer or plasticizer distribution shows up later as color streaks, bubbles and weak weld lines.
Can Prowell customize the PVC Mixer SHR-800*2/4000 Horizontal High Speed Mixing Unit?
Yes. The source plant states equipment is 100% customizable — pot volume, impeller, motor and discharge are sized to the recipe.
How do I request a quotation?
WhatsApp or email Jarvis with material, bulk density, kg/batch or kg/hour, and any heating/cooling requirement. Use [email protected] or +86 185 5118 6172.
Are the published models the only sizes?
The tables on this page are the models printed on the original Prowell listing. Other sizes are discussed against your batch weight.
