PVC Mixer Plastic High Speed Mixing Unit Blending Machine
The main body of SRL-Z series hot-cold mixing unit is composed of SHR series high-speed mixer and SHL series cooling mixer. This unit is mainly suitable for various resins such as polyethylene, polypropylene, polyvinyl chloride and other ingredients, mixing, coloring, drying, as well as ABS, polycarbonate and other engineering plastics before the molding process of drying, devolatilization and other processes, can also be used For the mixing of phenolic resin, it combines hot mixing and cold mixing together.
Uneven pigment, stabilizer or plasticizer distribution shows up later as color streaks, bubbles and weak weld lines.
How this machine is used
PVC Mixer Plastic High Speed Mixing Unit Blending Machine Vacuum Loader System Working principle of PVC Mixer In the actual production of the mixing unit, the materials are added to the SHR high-speed mixer through the feeding equipment according to the mixing process requirements for high-speed mixing and heating.
When the materials have completed the hot mixing process requirements, the high-speed mixer opens the material cutting device, and the qualified materials are directly poured into the barrel of the SHL cooling mixer through the discharge tee.
The material is in contact with the cooling equipment installed in the mixer through the low-speed mixing of the cooling mixer, and the temperature is quickly reduced.
After the materials have completed the above-mentioned process operations and qualified materials are obtained, they can be discharged from the equipment, packed and transported to the next production equipment or stored by conveying equipment or manpower.
Published specifications
| Model | Total Volume (L) | Effective Volume (L) | Paddle speed | Motor Power (kw) | Water Consumption | Discharging | Weight |
|---|---|---|---|---|---|---|---|
| SRL-Z100/200 | 100/200 | 75/160 | 650/1300/90 | 14/22/7.5 | 3.5t/h | Pneumatic | 3T |
| SRL-Z200/500 | 200/500 | 150/320 | 460/920/90 | 30/42/11 | 5t/h | Pneumatic | 3.5T |
| SRL-Z300/600 | 300/600 | 200/360 | 475/950/90 | 40/55/11 | 5.8t/h | Pneumatic | 3.8T |
| SRL-Z500/1000A | 500/1000 | 375/650 | 475/950/90 | 47/67/15 | 6.9t/h | Pneumatic | 5.8T |
| SRL-Z800/1600A | 800/1600 | 600/1024 | 370/740/68 | 60/90/22 | 10t/h | Pneumatic | 8T |
| SRL-Z800/2000A | 800/2000 | 600/1500 | 370/740/68 | 83/110/22 | 12t/h | Pneumatic | 8.5T |
| SRL-Z1000/3000A | 1000/3000 | 800/2200 | 66/68 | 160/30 | 15/h | Pneumatic | 10T |
Questions plants usually ask
What problem does the PVC Mixer Plastic High Speed Mixing Unit Blending Machine address?
Uneven pigment, stabilizer or plasticizer distribution shows up later as color streaks, bubbles and weak weld lines.
Can Prowell customize the PVC Mixer Plastic High Speed Mixing Unit Blending Machine?
Yes. The source plant states equipment is 100% customizable — pot volume, impeller, motor and discharge are sized to the recipe.
How do I request a quotation?
WhatsApp or email Jarvis with material, bulk density, kg/batch or kg/hour, and any heating/cooling requirement. Use [email protected] or +86 185 5118 6172.
Are the published models the only sizes?
The tables on this page are the models printed on the original Prowell listing. Other sizes are discussed against your batch weight.
