PVC Ceiling Material Frequency Conversion High Speed Mixer
SHR high-speed mixer is a kind of mixer with a wide range of use, and it can also be called high-speed mixer in general. It is one of the necessary equipment for plastic processing plants, and it is also widely used in rubber, pharmaceutical, dyeing and other industries. Because it has the advantages of fast mixing, uniform mixture, good absorption of the resin to the extender, easy operation of the machine, easy cleaning, sturdiness and durability, and compact structure. Now, it has gradually replaced the low-speed mixer and is widely used in the production of various plastic industries.
Uneven pigment, stabilizer or plasticizer distribution shows up later as color streaks, bubbles and weak weld lines.
How this machine is used
SRH 500 PVC Ceiling Material Frequency Conversion High Speed Mixer Plastic PVC Powder Mixer High Speed Heat Mixer Mixing Blade Features of PVC Ceiling Material Frequency Conversion High Speed Mixer 1.
The PVC mixer is mainly used to mix the formula of PVC ceiling materials and the formula of PVC wall panels.
The main shaft seal of the high-speed mixer adopts special material seal and oil-resistant and high-temperature-resistant skeleton oil seal.
The lid of the mixer adopts double sealing.
Published specifications
| Model | Volume | Effective volume | Motor | Spindle speed | Dimensions | Heating method | Uploading Method |
|---|---|---|---|---|---|---|---|
| SHR-5A | 5 | 3 | 1.1 | 1440 | 620*300*730 | Electricity/self-friction | Manual |
| SHR-10A | 10 | 7 | 3 | 1440 | 1200*300*830 | Electricity/self-friction | Manual |
| SHR-25A | 25 | 20 | 5.5 | 1440 | 1200*350*850 | Electricity/self-friction | Manual |
| SHR-50A | 50 | 35 | 7/11 | 750/1500 | 2100*700*1100 | Electricity/self-friction | Manual |
| SHR-100A | 100 | 75 | 14/22 | 650/1300 | 2100*800*1510 | Electricity/self-friction | Auto |
| SHR-200A | 200 | 150 | 30/42 | 475/950 | 2400*850*1580 | Electricity/self-friction | Auto |
| SHR-300A | 300 | 225 | 40/55 | 475/950 | 2800*1080*1680 | Electricity/self-friction | Auto |
| SHR-500A | 500 | 375 | 47/67 | 430/860 | 3060*1150*1880 | Electricity/self-friction | Auto |
| SHR-800A | 800 | 600 | 83/110 | 370/740 | 3385*1380*2750 | Electricity/self-friction | Auto |
| SHR-1000A | 1000 | 750 | 90/132 | 325/650 | 3460*1140*2900 | Electricity/self-friction | Auto |
| SHR-1300A | 1300 | 975 | 250 | 250/500 | 3600*1420*3100 | Electricity/self-friction | Auto |
Questions plants usually ask
What problem does the PVC Ceiling Material Frequency Conversion High Speed Mixer address?
Uneven pigment, stabilizer or plasticizer distribution shows up later as color streaks, bubbles and weak weld lines.
Can Prowell customize the PVC Ceiling Material Frequency Conversion High Speed Mixer?
Yes. The source plant states equipment is 100% customizable — pot volume, impeller, motor and discharge are sized to the recipe.
How do I request a quotation?
WhatsApp or email Jarvis with material, bulk density, kg/batch or kg/hour, and any heating/cooling requirement. Use [email protected] or +86 185 5118 6172.
Are the published models the only sizes?
The tables on this page are the models printed on the original Prowell listing. Other sizes are discussed against your batch weight.
