PVC Plastic Powder High Speed Mixing Machine
High Speed Mixing Machine is suitable for the mixing, coloring and drying of powder and granular materials in plastics, rubber, chemical, food and other industries. It is typically used in the preparation of PVC dry blends, plastic filling modification, initial mixing before extruder granulation, and multi-component mixing before wood-plastic production.
Uneven pigment, stabilizer or plasticizer distribution shows up later as color streaks, bubbles and weak weld lines.
How this machine is used
Plastic PVC Powder High Speed Mixing Machine with Automatic Loading System Components of Plastic Powder High Speed Mixing Machine PVC Plastic Powder High Speed Mixing Machine consists of seven parts: frame, transmission, pot body, lifting, discharge port and electric control box.
The whole machine adopts a closed structure, which is reasonable and beautiful.
The pot body is made of stainless steel, the inner surface is extremely smooth and hard, and it has the characteristics of wear resistance, corrosion resistance, and non-sticky materials.
The pot body of the mixer has a heating jacket and a resistance heating ring.
Published specifications
| Model | SRL-Z100/200 | SRL-Z200/500 | SRL-Z300/600 | SRL-Z500/1000 | SRL-Z800/1600 |
|---|---|---|---|---|---|
| Total volume (L) | 100/200 | 200/500 | 300/600 | 500/1000 | 800/1600 |
| Effective Volume (L) | 65/130 | 150/320 | 200/360 | 375/650 | 600/1024 |
| Rotating Speed (RPM) | 650/1300-180 | 475/950-87 | 475/950-87 | 430/860-60 | 357/714-50 |
| Mixing time (Min.) | 8-10 | 8-10 | 8-12 | 8-10 | 8-12 |
| Motor power (KW) | 14/22-7.5 | 30/42/11 | 40/55/11 | 55/75/15 | 83/110/22 |
| Overall dimension (mm) | 2500*2000*2200 | 4580*2240*2470 | 4800*2640*2480 | 5600*3000*3100 | 6230*4230*4480 |
| Weight (kg) | 2500 | 3600 | 4500 | 5800 | 8300 |
Questions plants usually ask
What problem does the PVC Plastic Powder High Speed Mixing Machine address?
Uneven pigment, stabilizer or plasticizer distribution shows up later as color streaks, bubbles and weak weld lines.
Can Prowell customize the PVC Plastic Powder High Speed Mixing Machine?
Yes. The source plant states equipment is 100% customizable — pot volume, impeller, motor and discharge are sized to the recipe.
How do I request a quotation?
WhatsApp or email Jarvis with material, bulk density, kg/batch or kg/hour, and any heating/cooling requirement. Use [email protected] or +86 185 5118 6172.
Are the published models the only sizes?
The tables on this page are the models printed on the original Prowell listing. Other sizes are discussed against your batch weight.
