F96B 50t/hr Automatic Filter Control Valves
F96B 50t/hr Automatic Filter Control Valves Specifications: Type Model Inlet/Outlet Drain Base Riser Pipe Brine Line Connector W.T.C (m³/h) Manual Filter Valve F56E 1/2″F or 3/4″F 2.5″-8NPSM 1.05OD / 2 F56A 1″F / 4 F56F 1″F 1″D-GB / 6.
- Range
- Control Valves
- Supplier
- Shanghai Liquapure Filtration Co., Ltd, Shanghai, China
- Customisation
- Micron rating, length and end cap specified to your housing
- Photographs on file
- 1
Details
Full Description
F96B 50t/hr Automatic Filter Control Valves
Specifications:
| Type | Model | Inlet/Outlet | Drain | Base | Riser Pipe | Brine Line Connector | W.T.C (m³/h) |
| Manual Filter Valve | F56E | 1/2″F or 3/4″F | 2.5″-8NPSM | 1.05OD | / | 2 | |
| F56A | 1″F | / | 4 | ||||
| F56F | 1″F | 1″D-GB | / | 6 | |||
| F56D | 2″F | 1.5″F | 4″-8UN | 1.5″D-GB 1.9″OD | / | 10 | |
| F77BS | 2″M | / | 15 | ||||
| F112BS | DN65 | Side-Mounted,Dn80 Top and bottom strainer connector | / | 40 | |||
| Automatic Filter Valve | F71B/F71P | 3/4″M | 3/4″M | 2.5″-8NPSM | 1.05″OD | / | 2 |
| F67C/F67B | 1″F | 1″F | / | 4 | |||
| F67B-A | 1″F | 1″F | 1″D-GB | / | 6 | ||
| F75A/F75B | 2″M | 2″M | 4″-8UN | 1.5″D-GB 1.9″OD | / | 10 | |
| F77B1 | / | 18 | |||||
| F95B/F95B3 | Side-Mounted,2″M Top and bottom strainer connector | / | 20 | ||||
| F112B/F112B3 | DN65 | DN65 | Side-Mounted,Dn80 Top and bottom strainer connector | / | 40 | ||
| F96B/F96B3 | DN80 | DN80 | Side-Mounted,Dn100 Top and bottom strainer connector | / | 50 | ||
| Manual Softener Valve | F64B/F64BC | 3/4″F | 1/2″M | 2.5″-8NPSM | 1.05″OD | 3/8″M | 2 |
| F64C | 3/4″F | 1/2″M | 2 | ||||
| F64A/F64AC | 1″F | 1/2″M | 4 | ||||
| F64F | 1.5″M | 3/4″F | 4″-8UN | 1.25″D-GB | 1/2″M | 6 | |
| F64D | 2″M | 1″M | 1.5″D-GB 1.9″OD | 10 | |||
| F77AS | 2″M | 1.5″M | 3/4″M | 15 | |||
| F112AS | DN65 | DN65 | Side-Mounted,Dn80 Top and bottom strainer connector | 40 | |||
| Automatic Softener Valve | F65B/F65P | 3/4″F | 1/2″M | 2.5″-8NPSM | 1.05″OD | 3/8″M | 2 |
| F63B/F63P | 1″M | 4 | |||||
| F74A/F74B | 2″M | 1″M | 4″-8UN | 1.5″D-GB 1.9″OD | 1/2″M | 10 | |
| F99A | 2″M | 1″M | 3/4″M | 15 | |||
| F77A | 2″M | 1.5″M | 18 | ||||
| F95A/F95D | 2″M | 1.5″M | Side-Mounted | 20 | |||
| F111A | 2″M | 1.5″M | 4″-8UN | 2″D-GB | 20 | ||
| F112A | DN65 | DN65 | Side-Mounted,Dn80 Top and bottom strainer connector | 40 | |||
| F96A | DN80 | DN80 | Side-Mounted,Dn100 Top and bottom strainer connector | 50 | |||
50T filter
FAQ
Questions About This Product
Will this fit my existing housing
Send us the housing brand and model, or the part number of the element you are replacing, and we will confirm what matches. The high flow line already covers 3M, Pall, Parker and Pentair equivalents.
Which micron ratings and lengths are available
Micron rating, length and end cap are specified per order. Tell us the duty and the housing and we will confirm what we can supply.
What is the production capacity
Spun filters 360,000 pieces, wound filters 100,000 pieces, pleated filters 8,000 pieces and high flow filters 1,000 pieces per day.
Which industries is this used in
Food and beverage, chemical, pharmaceutical, electronics and water treatment, among other filtration related industries.
How do I get a quotation
Call +86 137 6415 7715 with the specification and the quantity you need.
