High Temperature Axial Fan
GKW GWF Wood Drying Fan
Full-aluminum wall-type kiln fan for high-temperature, high-humidity wood drying.
Specifications →
High Temperature Axial Fan
WhatsApp this model
Email specifications
GKF GKT Drying Fan
Drying rooms need large volume at high temperature and humidity, not a comfort fan.
| Diameter | 250–1000 mm |
|---|---|
| Blades | 4–8 aluminum |
| Speed | 2900 / 1450 / 960 r/min |
| Protection | IP55 |
| Insulation | Class H 180 °C |
| Ambient | ≤130 °C, RH ≤98% |
| Dust limit | ≤150 mg/m³ |
| HS code | 8414599099 |
What this equipment is for
GKF/GKT axial fans with Class H motors, aluminum blades and a stated 130 °C ambient capability.
High-temperature axial drying fan for kilns, paint shops, tobacco and pharmaceutical drying.
- Diameters 250–1000 mm; 4–8 aluminum blades
- Speeds 2900 / 1450 / 960 r/min
- IP55; Class H 180 °C insulation; max ambient 130 °C; RH 98%
- Dust in gas ≤150 mg/m³; HS code 8414599099
Where it runs
Wood drying, Paint shops, Tobacco, Pharmaceuticals, Warehouses
Audience on the source page: Wood, paint, tobacco, rubber and pharmaceutical drying lines..
How hot can it run?
Source specifications list a maximum ambient of 130 °C and Class H 180 °C insulation.
What media is allowed?
Gas without corrosive content; dust and hard particles no more than 150 mg/m³.
