Mini Current Transformer
Moulded housing, resin housing, split core, ring type, mini, three phase, Rogowski coil, protection and residual current transformers.
| Category | Current Transformers |
| Type | Mini Current Transformer |
| Manufacturing | OEM to customer design, ISO9001 and ISO14001 |
Features
Meet the standard IEC60044-1 and ANSI C12.20
High accuracy class ,wide linearity
Superitor stability ,separate the external magneitc field interference
Measure the current directly
It is with the diode to save people's life
Meet the ROHS requirement
Specifications
| No. | Name | Materials /UL | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| 1 | Core | N42UU20.6 | ||||||||
| 2 | Winding | 2UEW/130 MW75-C Φ 0.16E255929 | ||||||||
| 3 | Outer Case | PA66 70G33L E41938 | ||||||||
| 4 | Lead Wire | UL1015 22AWG 600V 105°c (L=600mm) | ||||||||
| 5 | Diode | IN4738A 1W | ||||||||
Quick Details
Zhejiang, China (Mainland)
Current
Single
Toroidal, Micro Precision current transformer
Autotransformer
IEC60044-1 and ANSI C12.20
white
7mm
UL1015 22AWG 600V 105°c (L=600mm)
Epoxy Encapsulated transformer
Yes
Features
Meet the standard IEC60044-1 and ANSI C12.20
High accuracy class ,wide linearity
Superitor stability ,separate the external magneitc field interference
Measure the current directly
It is with the diode to save people's life
Meet the ROHS requirement
Specifications
| No. | Name | Materials /UL | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| 1 | Core | N42UU20.6 | ||||||||
| 2 | Winding | 2UEW/130 MW75-C Φ 0.16E255929 | ||||||||
| 3 | Outer Case | PA66 70G33L E41938 | ||||||||
| 4 | Lead Wire | UL1015 22AWG 600V 105°c (L=600mm) | ||||||||
| 5 | Diode | IN4738A 1W | ||||||||
Prev:Pin type mini current transformer Next:Loading type mini current transformer
FAQ
Email [email protected] with the product name, the rating and the accuracy class you need and the quantity.
Yes. Everfar is distinguished by OEM manufacture and develops customers' designs.
Everfar is qualified to ISO9001 and ISO14001, and holds product certificates including CE, UL and KEMA.
Send the rating and the quantity and our sales team will confirm the price.
