XUP400 Optical Polarizing Microscope
Item Specification XUP401 XUP402 XUP403 Eyepiece WF10X/22mm (adjustable) ● WF10X/22mm (adjustable, reticule 0.1mm) ● WF10X/20mm (adjustable) ● ● WF10X/20mm (adjustable, reticule 0.1mm) ● ● Professional Polarizing Seidentopf Binocular Head Inclined 30°, rotatable 360°, Interpupilary distance: 48mm~76mm ● ● ● Professional Polarizing Seidentopf Trinocular Head Inclined 30°, Rotatable 360°, Interpupilary Distance : 48mm~76mm,Light distribution(both) 100: 0(100% for eyepiece)80:20 (80% for trinocular head and 20% for eyepiece) ○ ○ ○ Non-stress Infinity Plan Objective (Transmitting) PLAN 4X/0.10 W.D.=10.00mm ● ● PLAN 10X/0.25 W.D.=2.10mm ● ● PLAN 20X/0.40(S) W.D.=2.41mm ● ● PLAN 40X/0.66(S) W.D.=0.45mm ● ● PLAN 60X/0.80(S) W.D.=0.33mm ○ Non-stress LWD Infinity Plan Objective (Reflecting) LPL 5X/0.13 W.D=24.23mm ● ○ LPL 10X/0.25 W.D.= 18.48mm ● ○ LPL 20X/0.40 W.D.= 8.35mm ● ○ LPL 50X/0.70(S) W.D.= 1.95mm ● ● Nosepiece Quintuple (center adjustable) ● ● ● POL Media Analyzer rotatable 360°, module type, can be locked ● ● ● Bertrand lens, Built In Center adjustable ● ● ● Slip Λslip(First Class Red) ● ● ● λ/4 slip ● ● ● Quartz wedge(Ⅰ~ Ⅳ) ● ● ● Revolving Round Stage Rotatable 360°, center adjustable, division 1°, vernier division 6’.
Application notes from the listing
Diameter: 148mm ● ● ● Swing-out Condenser N.A.0.9/0.13, polarizing unit ( with scale, rotatable 360°,can be locked) ● ● Coaxial Coarse and Fine Focusing Unit Coarse stroke 25mm, Fine stroke per rotation:0.2mm, fine division 2 μm ● ● ● Transmitting Illumination 6V/20W Halogen lamp(Input voltage:100V~240V) ● ● 6V/30W Halogen lamp (Input voltage:100V~240V) ○ ○ Reflecting Polarizing Unit With field diaphragm, aperture diaphragm ,polarizer, 12V/50W halogen lamp(Input voltage:100V~240V) ● ● Filter Blue ● ● ● Amber ○ ○ ○ Green ○ ○ ○ Neutral ○ ○ ○ Attached Polarizing Mechanical Stage ○ ○ ○ C-Mount 0.57 X (Focus adjustable) ○ ○ ○ 1X ○ ○ ○ Note: “●”In Table Is Standard outfits, “○” Is Optional Accessories.
Packaging Packing Size Gross Weight Net Weight XUP401 565mm×310mm×410mm 12.5 kgs 10 kgs XUP402 750mm×360mm×450mm 16 kgs 12.5 kgs XUP403 750mm×360mm×450mm 15 kgs 11.5 kgs
What should I send with a quote request?
The model name (XUP400 Optical Polarizing Microscope), binocular or trinocular preference, whether a camera is required, destination country, and any thread already on the stand.
Are extra specifications available?
Only values printed on the original AMADA listing are shown here. Missing numbers are TBC.
How do I order accessories for this model?
Open the matching accessory family and quote both product names in one email.
