13.3” AIOCAM4K ALL-IN-ONE Camera LCD Screen for Microscope
AIOCAM4K SERIES ALL-IN-ONE CAMERA AIOCAM4K Series All-in-One Camera Datasheet and Functions OrderCode Sensor&Size(mm) Pixel(μm) GSensitivityDarkSignal SensorOutput(FPS/Resolution) Binning Exposure(ms) AIOCAM4K8MPA Sony IMX678(C)1/1.8″(7.68×4.32) 2.0×2.0 3541mv with1/30s0.15mv with1/30s 60@3840*2160 1×1 0.019~1000 Camera Model Video Saving(FPS/Resolution) HDMI2.0(FPS/Resolution) USB3.0(FPS/Resolution) WiFi(FPS/Resolution) AIOCAM4K8MPA 60@3840*216060@1920*1080 60@3840*216060@1920*1080 30@3840*216045@2688*151260@1920*1080 30@3840*216060@1920*108060@1280*720 Multiple Language Support English /Simplified Chinese / Traditional Chinese / Korean / Thailand / French / German /Spanish / Japanese /Italian / Russian / Dutch / Portuguese Software Environment under WiFi/USB Video Output White Balance Auto White Balance Color Technique Ultra-Fine Color Engine Capture/ControlSDK Windows/Linux/macOS/Android Multiple PlatformSDK (Native C/C++, C#/VB.NET, Python, Java, DirectShow,Twain,etc) Recording System Still Picture or Movie Operating System Microsoft® Windows®8 / 8.1 /10 /11(32 & 64 bit)OSx(Mac OS X) Linux PC Requirements CPU: Equal to Intel Core2 2.8GHzor Higher Memory: 4GB or More Ethernet Port: RJ45 Ethernet Port Display:19” or Larger CD-ROM Operating Environment Operating Temperature (inCentidegree) -10。~50。 Storage Temperature (in Centidegree ) -20。~60。 Operating Humidity 30~80%RH Storage Humidity 10~60%RH PowerSupply DC12V/2A Adapter Interface or Button Function Description USB2.0 Connect USB mouse for easy operation with embedded XCamViewsoftware USB Video Connect PC or other host device to realize video image transmission USB3.0 Connect USB flash drive to save picturesand videos Connect 5G WiF module to transfe rvideo wirelessly in real time Connect USB microphone for audio and video recording ON/OFF Power switch (Short press to turn on, long press to turn off) HDMI OUT Comply with HDMI2.0 standard.
Application notes from the listing
Used to extend 4K/1080P format video out put and supporting automatics witch between 4K and 1080P format according to the connected monitors LED LED status indicator +/- Display brightness adjustment button MENU Display menu key DC12V2A Power adapter connection (12V/2A) Video Output Interface Function Description HDMI Interface Synchronize video output through HDMI OUT interface,comply with HDMI2.0 standard;60fps@4K Or60fps@1080P WiFi Interface Connecting 5GWiFi adapter (USB3.0 slot) in AP/STA mode USB Video Interface Connecting USB Video port of PC for video transferH264/MJPEG format video Other Function Function Description Video Saving Video format：8M (3840*2160) H264/H265 encoded MP4 file Videosaving frame rate :60fps in Low Delay mode; 30fps in WDR mode Image Capture 8M (3840*2160) JPEG/TIFF image in USB flash drive MeasurementSaving Measurement information saved in different layer with imagecontent Measurement information is saved together with image content in burnin mode ISP Exposure(Automatic / Manual Exposure) / Gain，White Balance(Manual /Automatic / ROI Mode)， Sharpening，3D Denoise，Saturation Adjustment，Contrast Adjustment，BrightnessAdjustment，Gamma Adjustment, Hue Adjustment, Color to Gray，50HZ/60HZAnti-flicker Function Image Operation Zoom In/Zoom Out(Up to10X), Mirror/Flip, Freeze, Video EDF, Cross Line,Overlay,PIP,Browser(including Picture Browsing, Video Playback, Video Compare, Picture Compare, Picture EDF, Image Processing), Measurement Function Embedded RTC(Optional) To support accurate time onboard Restore Factory Settings Restore camera parameters to its factory status Dimension of AIOCAM4K Series All-in-One Camera Figure3 Dimension of AIOCAM4K Series All-in-OneCamera AIOCAM4KSeries All-in-One Camera Packing Information Figure 4 AIOCAM4K Series All-in-One Camera Packing Information Standard Packing List A Gift box: L:35.6cmW:24.9cm H:7.5cm (1pcs,1.68Kg/ box) B AIOCAM4K Series All-in-One Camera C PowerAdapter: Input: AC100~240V 50Hz/60Hz, Output: DC12V 2A American standard: Model: POWER-12V2A(MX24Z1-1202000) +American standard plug European standard:Model: POWER-12V2A(MX24Z1-1202000) + European standard plug D USB wireless mouse E USB3.0A male to Amale gold-plated connectors cable /2.0m F CD (Driver & utilities software,Ø12cm) Optional Accessory G HDMI Cable H USB flashdrive I USB WiFi adapter J Adjustablelensadapter C-Mount to Dia.23.2mm EyepieceTube (Please choose1 ofthemfor yourmicroscope) 108001/AMA037108002/AMA050108003/AMA075 K Fixed lens adapter C-Mount to Dia.23.2mm EyepieceTube (Please choose1 ofthemfor yourmicroscope) 108005/FMA037108006/FMA050108007/FMA075 Note: For J and K optional items, please specify your camera type(C-mount, microscopecameraor telescopecamera),our engineer will help you to determine the right microscope or telescope camera adapter for your application; L 108015(Dia.23.2mm to 30.0mm Ring)/Adapter rings for 30mm eyepiece tube M 108016(Dia.23.2mm to 30.5mm Ring)/Adapter ringsfor 30.5mm eyepiece tube N Calibration kit 106011/TS-M1(X=0.01mm/100Div.); 106012/TS-M2(X, Y=0.01mm/100Div.); 106013/TS-M7(X=0.01mm/100Div., 0.10mm/100Div.) Note: If you need Optional Accessory, please contact me for price.
What should I send with a quote request?
The model name (13.3” AIOCAM4K ALL-IN-ONE Camera LCD Screen for Microscope), binocular or trinocular preference, whether a camera is required, destination country, and any thread already on the stand.
Are extra specifications available?
Only values printed on the original AMADA listing are shown here. Missing numbers are TBC.
How do I order accessories for this model?
Open the matching accessory family and quote both product names in one email.
