Busbar Processing Machine
Angle Steel Punching and Shearing Machine
Busbar processing machines punch, shear, bend, chamfer and saw copper and aluminium bar for switchgear and electrical distribution assembly.
- Built by Ningbo Anchors Precision Machinery Co., Ltd. in Ningbo, China
- Full manufacturer parameter table on this page
- Machine video available on request
- Rapid response technical team for operation and troubleshooting
Have a drawing? Send it straight to WhatsApp or email — there is no form to fill in.
Angle Steel,channel Steel Punching and Shearing Machine Specifications
| MODEL | UNIT | AKS-AC-8 | AKS-AC-10 | AKS-AC-12 |
|---|---|---|---|---|
| MAX. SHEARING FORCE | KN | 400 | 550 | 1000 |
| CUTTER STROKE | MM | 27 | 30 | 36 |
| STROKE PACE | TIMES/MIN. | 30 | 30 | 30 |
| MOTOR POWER | KW | 2.2 | 3 | 4 |
| DIMENSION | CM | 95*50*117 | 100*63*130 | 110*60*150 |
| WEIGHT | KG | 550 | 750 | 1150 |
Angle steel,channel steel punching and shearing machine capacity
Angle Steel,channel Steel Punching and Shearing Machine Applications and Features
Application:
Multifunctional punching and shearing machine for angle steel,channel steel ,steel bar.Multifunctional punching and shearing machine is used for cutting, punching, engraving, angle carving and other processing of angle steel, flat steel, round steel, square steel, channel steel and other metal materials.
It uses overlapping two-stage levers and sliders to drive the slide plate with three cutting blades to move up and down, and the cutters mounted on the frame complete the cutting and punching processing. The equipment is compact in structure, versatile in function, small in size, light in weight and easy to operate.
Angle Steel,channel Steel Punching and Shearing Machine Structure and Components
Angle/round steel cutting station angle/channel steel punch station Carved angle station.
Related Products
Other Models in Busbar Processing Machine
Same family, different size range and station count.
CNC Busbar Punching and Shearing Machine
Three Station Multi Functions Bus Bar Making Machine
CNC Busbar Angle Chamfer Milling Machine
Open Type Hydraulic Busbar Forming Machine
Closed Type Hydraulic Busbar Bending Machine
Portable Copper Bar Processing Machine
Simple Busbar Shearing Punching Bending Machine
CNC Busbar Segment Sawing Machine
Questions and Answers
Angle Steel Punching and Shearing Machine FAQ
What is the Angle Steel Punching and Shearing Machine used for?
Can I get the technical specification for my size range?
Is this machine built by Anchors Machinery?
Can it be supplied together with the upstream and downstream machines?
What support do I get after delivery?
How do I request a price for this machine?
Send the Part, Get the Machine Specification
A drawing or a clear photo plus your required output is enough for us to confirm the model and tooling.
Send drawings, samples or part specifications by WhatsApp or email — no forms, no sign-up.
