Ball head joint hexagon screw cold forging machine
This Wedge anchor bolt automatic cold forging machine is special designed for making concrete wedge anchors bolts,it adopts the cold forging method, Suitable…
- Built by Ningbo Anchors Precision Machinery Co., Ltd. in Ningbo, China
- More than twenty years experience in cold and hot forging and metal stamping equipment
- Rapid response technical team for operation guidance and production support
Watch Machine Video
Running video of Ball head joint hexagon screw cold forging machine
Application of Ball head joint hexagon screw cold forging machine
This Wedge anchor bolt automatic cold forging machine is special designed for making concrete wedge anchors bolts,it adopts the cold forging method, Suitable for forging many kinds of concrete wedge anchors and through bolts. The forging machine can automatically finish function of raw steel wire feeding,wire straightening,wire cutting, wedge anchor head forging,wedge anchor neck forging and bolt end forming.Compare with multi stations bolt former,the machine investment is much lower also die cost and maintanance cost are much lower than multi stations bolt former.
Specifications of wedge anchors rod bolt forging machine sheet one
| 1 | Model: | AW23-6 | AW23-8 | AW23-8L | AW23-10 | AW23-10L | AW23-10LL |
|---|---|---|---|---|---|---|---|
| 2 | Suitable Sizes: | M4-M6 | M6-M8 | M6-M8 | M6-M10 | M6-M10 | M6-M10 |
| 3 | Max. Shank Length: | 60 | 120MM | 150MM | 120MM | 150MM | 200MM |
| 4 | Max. Production Speed: | 60PPM | 50PPM | 50PPM | 50PPM | 50PPM | 50PPM |
| 5 | Main Motor Power: | 4KW | 5.5KW | 5.5KW | 7.5KW | 7.5KW | 11KW |
| 6 | Appro. Weight: | 2.5T | 3T | 3.8T | 5.8T | 6.5T | 7T |
| 7 | Appro. Dimension: | 123*88*105CM | 235*140*135CM | 270*150*145CM | 330*160*145CM | 352*190*170CM | 400*200*180CM |
Specifications of wedge anchors rod bolt forging machine sheet two
| 1 | Model: | AW23-12 | AW23-12L | AW23-16 | AW23-20 | AW23-20L | AW23-30 |
|---|---|---|---|---|---|---|---|
| 2 | Suitable Sizes: | M8-M12 | M8-M12 | M10-M16 | M16-M20 | M16-M20 | M24-M30 |
| 3 | Max. Shank Length: | 150MM | 200MM | 200MM | 250MM | 300MM | 300MM |
| 4 | Max. Production Speed: | 50PPM | 45PPM | 45PPM | 40PPM | 30PPM | 25PPM |
| 5 | Main Motor Power: | 11KW | 15KW | 18.5KW | 22KW | 30KW | 55KW |
| 6 | Appro. Weight: | 8T | 8.5T | 10T | 15.8T | 23.5T | 45T |
| 7 | Appro. Dimension: | 450*210*188CM | 480*220*190CM | 590*235*180CM | 630*240*180CM | 640*250*200CM | 700*280*260 |
Features of Ball head joint hexagon screw cold forging machine
(1) Perfect design, easy operation,one process cold forging to get finished blank of wedge anchor bolt,no any material waste.
(2)Fingerless workblank transfter system design,increased the transfer system steady and high performance,meanwhile decreasing machine maintenance point and save cost of compressed air system compare with neumatic air finger system..
(3)Single rail skid way design make the machine runs in high speed, and the production efficiency is also high.Major parts of the wedge anchor bolt forging machines are made from high quality material, undergoing high abrasion-resistance and low deformation heat treatment process, the machine is endurable with long time preciseness
(4) Our machines adopt the forced oil feeding system, to make sure all components of the machine run in films of oil condition, and the machine could be durable for long time.
(5) The key components of our machines are imported from Taiwan, Japan and Germany, which are all complied with the all high-precision, high-hardness, high-abrasion resistant requirements.
(6) Male mould ejection design, which solve the bolts blocking problem when running down,PKO system is optional.
(7) Perfect apperance of forged wedge anchor bolt blank,the quality and apperance is similar as some world famous brands of wedge anchor fasteners,like Hilti,Trubolt,Redhead..etc.
